TECHNICAL INFORMATION
SOUND SPECIFICATION
• ACTIVE STEREO LOUDSPEAKER WITH BASS REFLEX SYSTEM
• CLASS D AMPLIFIERS: 2X20W+1X50W
• 1” DOME TWEETERS: 2X (FERROFLUID COOLED)
• 5¼” WOOFERS: 2X
• MAX SPL: 110DB @ 1M (GROUND PLANE 300HZ 3%THD)
• BASS AND TREBLE TONE CONTROLS
• FREQUENCY RANGE: 35- 22.000HZ
• CROSSOVER FREQUENCY: 2800HZ
CONNECTIVITY
• BLUETOOTH: STANDARD V4.0 + EDR aptX® CODEC
• INPUT 1 - 3.5MM: 1X
• INPUT 2 - RCA: 2X
• OPTICAL INPUT: 1X
TECHNICAL INFORMATION
• MAINS INPUT VOLTAGE: 100-240V~ /200W
• ABSOLUTE MIN/MAX: 90-264V~
• MAINS FREQUENCY: 50-60HZ
• MAX PEAK POWER CONSUMPTION: 200W
• TWO STANDBY MODES: POWERSAVER MODE (0,43W)
AND STANDARD MODE (8,7W)
• MAX POWER OUTPUT: 80W RMS
• WEIGHT: 7.90KG / 17.42 LBS
• SIZE: 400 x 308 x 200MM / 15.75 x 11.40 x 7.87IN
NOTE: THE FRONT FRET IS NOT REMOVEABLE. THIS ILLUSTRATION INTENDS TO
SHOW THE INTERNAL SPEAKER LAYOUT. DO NOT ATTEMPT TO REMOVE THE
FRONT FRET FOR RISK OF DAMAGING YOUR ACTIVE LOUDSPEAKER.
