Marshall Electronics CV630-IP User Manual

English - 29
6.1.2 Using the Browser to View the Images
■ Open the browser, and enter the URL of CV630-IP in the IP address bar
e.g.: http://192.168.100.100 (default IP address)
■ Enter administrator’s account and password
6.1.3 Using Marshall VMS Software to View the Images
■ Open MARSHALL VMS software
■ Search for the camera: Press [automatically search for the device] button to
locate the CV630-IP camera
■ Click CV630-IP in the list and start operation after connecting to network
<Note> When using automatic search, the camera and computer must be in the
same network segment, e.g.: 192.168.4.X
6.1.4 Using RTSP Player to View the Images
In addition to the software GUI in internet browser and VMS, other free software als
can be used for RTSP connections, such as VLC, Quick Time and PotPlayer
RTSP connection address formats are as follows:
● RTSP Main Streaming => rtsp://camera IP:8554/hevc
● RTSP Sub1 Streaming => rtsp://camera IP:8557/h264
● RTSP Sub2 Streaming => rtsp://camera IP:8556/h264
Example: Open VLC software and enter URL: rtsp://192.168.100.150:8557/h264
Marshall IP Camera
I Account: admin
I Password: 9999

Marshall Electronics CV630-IP Specifications

General

Megapixel	8 MP
Camera type	Single camera
Sensor type	-
Optical zoom	30 x
Zoom capability	Yes
Optical sensor size	1/2.5 \
Vertical field of view (wide)	70 °
Networking standards	IEEE 802.3at
Maximum frame rate	- fps
Supported video modes	720p, 1080p, 3840p
Video formats supported	H.264, H.265, HEVC
Maximum video resolution	3840 x 2160 pixels
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3840 x 2160
Pan range	0 - 340 °
Product color	Black
Tilt angle range	0 - 120 °
