VMV-402-SH Manual
1. Introduction
2. Features
The VMV-402-SH Quad-viewer/Switcher enables instant seamless switching or quad-view display of up to four SDI
video signals with independent audio meters. The VMV-402-SH is pre-programmed with ve default quad-view layouts,
and is ideal for presentations and control rooms that require multiple inputs to be displayed on a single screen.
The embedded processor converts signals from input sources to match the native resolution of monitors, at panel
displays and projectors, with user-selectable output settings up to 4K2K 60HZ (HDMI output). SDI output resolution up
to 1920x1080p. Additional output adjustments include brightness, contrast, hue and saturation.
3
www.marshall-usa.com
• Supports four 3G/HD/SD-SDI input video formats
• 4 individual buttons for full screen selection and 1 button for quad-view mode
• HDMI output supports up to 4K2K@60 (UHD 3840x2160)
• Supports USB, IR and ethernet control
• One SDI and one HDMI output
• Supports standard VESA resolution for HDMI output
• Firmware upgradable via USB
• Illuminated buttons indicate currently selected source
• Pre-programmed with ve default quadview layouts
• Supports tally function on quad-view output
3. Package Contents
1x VMV-402-SH
2x 1U rack mounting-ears
1x 24V 5A power adapter
1x UL AC power cord
1x IR Remote Control
1x IR Receiver
1x Installation software CD
Please take a moment to ensure that the following is included with the VMV-402-SH:
