JR101017a
4
Marshall Electronics
4. Specifications
Model Name VMV-402-SH Quad-viewer/Switcher
Role of Usage Quad-viewer or 4x1 Video Switcher
Video Input Support
[3G] 1080p @50/59.94/60Hz (4:2:2)
[HD] 720p @50/59.94/60Hz, 1080i @50/59.94/60Hz, 1080p @24/30/60Hz
[SD] NTSC @59.94Hz, PAL @50Hz
Audio Support Embedded surround sound (up to 7.1ch) or stereo digital audio
ESD Protection Human body model — ±12kV [air-gap discharge] & ±8kV [contact discharge]
Input 4x BNC [SDI]
Program Output 1x HDMI + 1x BNC(SDI)
HDMI connector Type A [19-pin female]
RJ-45 connector WE/SS 8P8C
Mechanical
Housing Metal enclosure
Dimensions [L x W x H] 190 x 180 x 44mm [6.5 x 2.8 x 1"]
Weight 1kg [2.2 lbs]
Mounting 1U rack-mounting case with ears
Power supply 24V 5A DC
Power consumption 25 Watts Nominal
Operation Temperature 0~40°C [32~104°F]
Storage Temperature -20~60°C [-4~140°F]
Relative Humidity 20~90% RH [no condensation]
