VS-570-HDSDI User Manual
2.0 Megapixel Speed Dome Manual
Serial Data
• RS-485 support:
• Data pass-through mode: Serial data communication between VS-570-HDSDI and Decoder.
Sensor and Alarm
• Supports direct connections of external sensor and alarm devices.
• Event Alarm notification.
• 2 alarm sensor Inputs and 2 alarm Output relays are available.
• If an external sensor is activated, camera can be set to move to the corresponding Preset
position.
User Interface
• Diagnose and upgrade a through dedicated program called True Manager.
• System configuration using Internet Explorer
High Reliability
• Reliable embedded system.
Powerful Pan/Tilt Functions
• Max. 360/sec high speed Pan/Tilt Motion.
• Using Vector Drive Technology, Pan/Tilt motions are accomplished in the shortest path.
As a result, the time to target view is reduced dramatically and the video on the monitor is very
stable.
• When using a PTZ controller, the ultra slow speed of 0.05/sec is usefull for accurately moving
the camera to a desired view. Additionally, the zoom-proportional pan/tilt movement improves
the ability to follow a moving object.
Preset, Pattern, Swing, Group
• MAX. 128 Presets are assignable and characteristics of each preset can be set up
independently.
• Max. 8 sets of Swing action can be stored. This enables you to move the camera repetitively
between two preset positions with a designated speed.
• Max. 4 of Patterns can be recorded and played back. This enables to move camera to follow
any trajectory operated by a joystick as closely as possible.
• Max. 8 sets of Group actions can be stored. This enables you to move camera repetitively
with a combination of Preset or Pattern or Swing. A Group is composed of a maximum
of 20 entities of Preset/Pattern/Swings.
