Copyright © 2020 Martin Audio Ltd. 10
ADORN USER GUIDE V1.0
ADORN USER GUIDE
Fit the wall part of the bracket to the ceiling bracket (CDDCB5) with the fastenings supplied.
Connect the two assemblies together using the M6 x 60 supplied with we wall bracket. This configuration will give you tilt adjust only.
If “pan & tilt” adjustment is needed repeat the above process with the pan and tilt coupler included.
