Copyright © 2020 Martin Audio Ltd. 8
ADORN USER GUIDE V1.0
ADORN USER GUIDE
ADORN On-wall Deployment
Wall-mounting
The ADORN on-wall loudspeakers are supplied with a bracket to ensure trouble free installation. The bracket is a three-part design which
allows adjustment in both horizontal and vertical planes.
The first stage is to disassemble the bracket so that the cabinet half can be fitted to the speaker and the wall section attached to the wall.
A 4mm Allen key is required. If adjustment is only required in one plane, vertical or horizontal, the middle section can be removed. This
has the added advantage that the speaker will be closer to the wall.
Fit the wall bracket in the appropriate orientation for horizontal or vertical adjustment. Fixings appropriate for the wall surface and weight
of the cabinet must be used to ensure a safe and secure installation.
