1.5 Connecting Inputs
Input connections are made via the 3-pin XLR-female type or 1/4" phone Jack connectors on the rear side of
the amplifier.
The figure below shows the connection of analog input for balanced and unbalanced line. You can use either
configuration, but you must consider that unbalanced long lines can introduce noise in the audio system.
The Link switch located in the rear panel is for direct paralleling the rear input connectors. You can use the
remaining input connector to carry signal to other amps.
