Acrobat user manual DMX protocol 21
DMX PROTOCOL A
Channel Value Percent Function
1
0 - 4
5 - 154
155 - 169
170 - 229
230 - 239
240 - 249
250 - 255
0 - 1
2 - 60
61 - 66
67 - 89
90 - 93
94 - 97
98 - 100
Dimmer, Strobe, Reset
Light off
Dimmer, closed to open
Dimmer full open
Strobe, fast to slow
Stand-alone, music trigger
Stand-alone, auto trigger
Reset
2
0 - 1
2 - 122
123 - 132
133 - 253
254 - 255
0 - 1
1 - 48
49 - 52
52 - 99
99 - 100
Parabolic Reflector
Stop
CCW rotation, slow to fast
Stop
CW rotation, fast to slow
Stop
3
0 - 11
12 - 23
24 - 35
36 - 47
48 - 59
60 - 71
72 - 83
84 - 95
96 - 107
108 - 119
120 - 131
132 - 143
144 - 155
156 - 167
168 - 179
180 - 191
192 - 203
204 - 215
216 - 227
228 - 239
240 - 255
0 - 4
5 - 8
9 - 13
14 - 18
19 - 23
24 - 27
28 - 32
33 - 37
38 - 41
42 - 46
47 - 51
52 - 55
56 - 60
61 - 65
66 - 70
71 - 74
75 - 79
80 - 84
85 - 88
89 - 96
97 - 100
Color / Gobo Wheel
Open
Worms
Web
Petals
Spokes
Cone
Maze
Crater
Holes
Cross
Jagged Cross
Atomic
Dot Circle
Nordic
Aim
Pie
Tie
Nova
Triple Beam
Blackout
Random “stand-alone” position w/ music or auto trigger
4 0 - 255 0 - 100
Mirror Drum Swivel
Left to right (127 = neutral)
5
0 - 1
2 - 122
123 - 132
133 - 253
254 - 255
0 - 1
1 - 48
49 - 52
52 - 99
99 - 100
Mirror Drum Rotation
Stop
CW rotation, slow to fast
Stop
CCW rotation, fast to slow
Stop
6 0 - 2
3 - 255
0 - 1
2 - 100
Mirror Swivel Speed
Tracking (speed function off)
Fast to slow
7*
0 - 255 0 - 100
Color / Gobo Speed (*extended mode only)
Fast to slow
