Installation
10. Position the installation frame on the operator side (Fig. 9).
11. Fix the installation frame with screws (Fig. 10).
Fig. 9: Positioning the installation frame on the operator side
Fig. 10: Securing the installation frame
NOTE
Do not tighten the screw connection yet.
