Marvel MicroSentry 30WCM - Page 25

MICROSENTRY™ REFRIGERATION MONITOR
Service Parts List Two: 30WCM Cabinet
Illus. No. Description Qty. Req. Part No. Service Assembly
1 Strain Relief 1 32175-000
2 # 10 x .5 Type AB Hex Washer HD Screw 26 08204928
3 Back Panel 1 41006763
4 Sensor 1 41050117
5 Screw 1 08204928
6 Fastex Clamp #8511-33-00, White 2 41003685
7 Hinge, Chrome, Right, Top 1 41007433
8 10-32 x 3/4 PH Screw, Taptite, Zinc 6 41007598
9 Main Wire Harness 1 41050106
10 Wire Conduit 1 41010758
11 Light Bulb 15T7N - 130V 1 41003558
12 Light Socket 1 41006862
13
Mounting Clip
(supplied with Electronic Controller)
2
14 Display Housing 1 41010680
15 Light Switch, Black 1 41050101
16 Door Switch, Black 1 41050103
17 Electronic Controller 1 41050100
18 Lock Washer, SS 2 41010640
19 Screw 2 08204928
20 Screw 2 41010354
21 Maplewood Shelf Front 5 41010792
22 Sliding Shelf, Black 5 41010821-001
23 # 8 x 2 Type AB Hex Washer HD Screw, SS 20 41010764
24 Support Peg Washer, Black 20 41010790-001
25 Shelf Mounting Peg, Black 20 41010789-001
26 Screw 2 41007598
27 Bottle Cradle 1 41010795
28 Pop Rivet # AD43ABS Aluminum 2 08204930
29 Drip Tray, Black 1 41006858
30 Drain Tube, Black 1 41007166
31 # 12 x 3/4 Type AB, PH Black 2 41008206
32 Toe Grille, Black 1 41010317
33 Hinge, Chrome, Right, Bottom 1 41007434
34 1” Spacer, Black 2 41007165
35 Screw 2 44000264
36 Screw 2 08204928
37 Evaporator Assembly, Black 1 42053667
