MICROSENTRY™ REFRIGERATION MONITOR
25
Service Parts List Three: 30WCM Mechanical
Illus. No. Description Qty. Req. Part No. Service Assembly
1 Fan Shroud 1 41005500 42242902
2 Condenser, R-134a 1 41003609 42242082
3 Copper Tube, .312 OD x 4.50 LG 1 41003637
4 Dryer, 1/4 x 5/16 x 3/32 1 41001460 42243394
5 Discharge Tube, .187 OD x 19 LG 1 41003636 42244850
6 Baseplate, R-134a Mechanical 1 41006681
7 Hex Nuts 6 41006874
8 Fastex Clamps 4 41003685
9 Screw 4 41005086
10 Mounting Screws 2 41003221
11 Tinnerman Nut 1 41000153
12 Fan Blade, Morrill 1 41003616 42242015
13 Silencer 1 M000101A
14 Fan Motor Bracket 1 1010002B
15 Fan Motor 1 41006539
16 Process Tube 1 41005794 42242896
17 Lock Nut 3 08205051
18 Tecumseh Compressor, R-134a 1 41007131 42242388
19 Overload 1 41007220 42245133
20 Terminal Cover 1 41007221 42245132
21 PTC Relay 1 41007219 42245131
22 Mounting Grommet 4 32014-000
23 Flat Washer 3 08204877
24 Run Capacitor 1 41007222 42245134
25 Mounting Sleeve 3 32015-000
26 Lock Washer 1 08205115
27 Ground Wire, Green 1 41001401
28 Lock Washer 1 41005417
29 Wiring Harness 1 41010392
30 Power Cord, 6RFI 1 1180006B 42241948
31 10-24 x .5 UNC 2 Carriage Bolts 6 1130006A
32 1/4-20 x 1.5 Carriage Bolts Z/P 3 44000227
33 Pop Rivet 4 41003962
