MICROSENTRY™ REFRIGERATION MONITOR
Service Parts List Two: 6BARM Cabinet
Illus. No. Description Qty. Req. Part No. Service Assembly
1 Back Shroud 1 41003617
2 Screws 17 08204928
3 Back Panel 1 41000396 42241648
4 Sensor 1 41050117
5 Screw 1 08204928
6 Fastex Clamp #8511-33-00, White 4 41003685
7 Hinge, Chrome, Right, Top 1 41007433
8 Hinge Screw, Zinc 6 41007598
9 Wire Harness 1 41050112
10 Wire Harness 1 41050106
11 Wire Conduit 1 41010757
12 Evaporator Assembly, Black 1 42056608
13 # 8 x 2 Type AB Hex Washer HD Screw, SS 3 41010764
14 Evaporator Spacer, Black 3 41006404
15 Light Bulb 15T7N - 130V 1 41003558
16 Light Socket 1 41006862
17
Mounting Clip
(supplied with Electronic Controller)
2
18 Display Housing 1 41010777-001
19 Light Switch 1 41050101
20 Door Switch 1 41050103
21 Electronic Controller 1 41050100
22 Lockwasher 2 41010640
23 Screw 6 08205079
24A French Door Shelf, Black 1 41010729-001
24B French Door Shelf Assembly, Black 1 42136591-001
25 Maplewood Shelf Front 2 41010793
26 Screw 5 41010354
27 Glass Shelf 2 41005466
28A Sliding Shelf, Black 1 41010788-001
28B Sliding Shelf Assembly, Black 1 42136569-001
29 # 8 x 2 Type AB Hex Washer HD Screw, SS 4 41010764
30 Support Peg Washer, Black 4 41010790-001
31 Shelf Mounting Peg, Black 4 41010789-001
32 Screws 2 41007598
33 Bottle Cradle 1 41007590 42244618
34 # 12 x 2/4 Type AB, PH Screw, Black 2 41008206
35 Grille, Black 1 41005059 42242366
36 Hinge, Chrome, Right, Bottom 1 41007434
37 Drain Tube, Black 1 41006401
38 Drip Tray, Black 1 41006402
39 Pop Rivet # AD43ABS Aluminum 2 08204930
Not Shown P-Clamp 1 41010736
41
