5. Gearshift Indicator
This indicator will show the current gear selected. There are 4 gears. The 4
numbers will be lit on your dashboard. However, when the gears are in
neutral, no number will show, and only neutral indicator (N) will be lit.
6. High beam indicator lamp
When the head light is on high beam, this indicator is lit.
7. Trip mileage recorder
Indicates the distance traveled since last reset
8. Indicator neutral mode
Light comes on when gears are in neutral.
Ignition switch
FIG. 1
There are four positions as shown in following sketches
OFF Position
All circuits are disconnected and the key can be removed.
ON Position
All ignition circuits are ON and the engine can be started. The key cannot
be removed in this position.
Handlebar Lock Position
In order to lock the handlebars, turn the bars fully to the left, then insert
the key. Rotate it clockwise to this position and remove
Parking position.
To park the motorcycle at night, turn the key to ā ā position.
In this position, the key can be removed and the tail lamp and
front side light will remain on.
