Front brake light switch
The switch of front brake light is located below the brake grip. Loosen the screw
and move the switch position back and forth to find a proper point so that the
lamp is lit immediately when pressure is applied but before the lever is fully
pressed.
Rear Brake
Adjustment of rear-wheel brake,
If the rear brake is drum brake, to adjust the rear-wheel brake
pedal, set the pedal to the most comfortable position for driving
by rotating the pedal adjustment nut. Then, rotate the free play
adjusting nut (2) to keep the free play (1) between 20-30mm.
