Masibus MINT-AOV-08 User Manual

Page | 24
MINT – IO
REF NO: m25A/om/101
Issue No: 11
3.2.3 mINT-CP diagnostics modnet address
Fully diagnostic data of CP can be read from this range of addresses.
Parameter
Address
Description
COM 2 State
32002
0: no error and using;
1: not to be used;
Number of
Requests
32101, 32102
Total number of requests from
the master
Unsigned 32-bit integer
Number of Valid
Responses
32103, 32104
Total number of responses to
the master
Unsigned 32-bit integer
Number of Invalid
Responses
32105, 32106
Total number of responses to
the master
Unsigned 32-bit integer
Running Time
32107 –
SECOND
32108 – MINUTE
32109 – HOUR
32110 – DAY
Time elapsed, in seconds
Unsigned 32-bit integer
DIP Switch
32010
Status of DIP Switch on Front
Panel
Software Version
32001, 32002
4 unsigned 8-bit integers
Parameters Version
32003, 32004
4 unsigned 8-bit integers
Software Type
32005,32006
Type ID of I/O module
Part Name
32007 -32018
Part Name of mint-CP module.
com-1 status
32019
0: no error and using;
1: not to be used;
com-2 status
32020
0: no error and using;
1: not to be used;
IP address
32023 -32026
Mint-CP IP address
IP Mask
32027 - 32030
Mint-CP IP mask address
TCP Port
32031
Ethernet – Port
Station no
32032
Modnet Device ID
No. of request
32033 - 34
Modbus RTU master send
request to slave
No. of valid-res
32035 - 36
Valid response for sent request
from slave to master
