Page | 35
MINT – IO
REF NO: m25A/om/101
Issue No: 11
4.2.3 Status Indicators
Power: “ON” When Logic Supply is “ON”
Module Status: “ON” When CPU is Running
RS 485 RX1- RX2: Flashes when Modbus queries are receiving
RS 485 TX1- TX2: Flashes when transmitting Modbus response
Output Status: “ON” when Output is “ON”
“OFF” when Output is “OFF”
