4.1.3 Status Indicators
 Power: “ON” When Logic Supply is “ON”
 Module Status: “ON” When CPU is Running
 RS 485 RX1- RX2: Flashes when Modbus queries are receiving
 RS 485 TX1- TX2: Flashes when transmitting Modbus response
 Input Status: “ON” when Input is “ON”
“OFF” when Input is “OFF”
