Masibus UT-94 - Power Supply; Physical & Environmental; Advance Option

UNIVERSAL TRANSMITTER UT-94
REF NO: m98A/om/101
Issue NO: 15
User’s Manual Page 22 of 25
12.6 Power Supply
Standard
: 85-265VAC/ 100-300VDC
Optional
: 18-36VDC
Power consumption
: <10 VA
12.7 Isolation (Withstanding voltage):
* Three port isolation i.e. between input/output/power supply (1500VAC for 1 minute)
12.8 Insulation resistance:
2000MΩ or at 500 V DC between input, output and power supply.
12.9 Physical:
Size
: 55(W) x 75(H) x 110(D) mm
Mounting
: Din Rail
Terminal Cable Size
: 2.5mm
2
Weight
: < 250 gm
12.10 Environmental:
Operating temperature
: 0-55 °C
Storage temperature
: 0-80 °C
Humidity
: 20-95 % RH non-condensing
12.11 Advance Option:
Digital Filter
: 0-60 Second
Password Setting
: Available
Square Root
: Available for linear inputs only
Output Direction
: Direct / Reverse (programmable)
Output Signal Limit
: Available (low and high)
Engineering Unit
: °C, °F, °K (for T/C and RTD inputs)
Decimal Point
: Programmable for linear inputs
Scaling for Retransmission output
: Min limit: 0-30 % for Output Zero, Max limit: 70-100 % for Output Span
