UNIVERSAL TRANSMITTER UT-94
REF NO: m98A/om/101
Issue NO: 15
User’s Manual Page 9 of 25
6. Menu Function List
PROG
ST-1
Set point value for relay-1
HY-1
0 TO 100
ST-2
Set point value for relay-2
HY-2
0 TO 100
* Output will not be scaled but only limit to this configured % of output.
CONF
INP
IPTY
T/C: E, J, K, T, B, R, S, N.
RTD: Pt100 3-WIRE, Linear: mV(-10 - 500mV), Pot(0-2000 Ohms), 0-2V,
0.4-2V, 0-5V, 0-20mA, 1-5V, 4-20, 0-10V.
Zero
Input Zero Value
Span
Input Span Value
DP
0 - 3
UNIT
°C,°F,°K
INLO
For I/P Type: mV(-10 - 500mV), Pot(0-2000 Ohms)
INHI – INLO >10
INHI
OUT
rtr
OPNO
1, 2
OPTY
4 –20mA, 0 –20mA, 1-5V, 0-5V, 0-10VDC
Op Z
% of Output for scaling
(O/P Zero limit will be limited to this configured 0-30 % of O/P Span)
OP S
% of output for scaling
(O/P Span limit will be limited to this configured 70-100 % of O/P Span)
OPLO
* % of Output
(O/P Low limit will be limited to this configured 0-25 % of O/P Span)
OPHI
* % of output
(O/P Hi limit will be limited to this configured 75-100 % of O/P Span)
OPSC
UPSC/DNSC
DIR
DIR/REV
rely
RLNO
1, 2
OPSE
UP,dw
LOGC
HI,low
C AL
ALARM,TRIP,OPEN
LTCH
YES,NO
COM
SRNO
1-247
BAUD
4800,9600,19200
ADV
FILT
0 - 60 Sec
FSET
Give Default password for factory settings
PASS
Change Password
SQRT
YES/NO
TOUT
10-300 SEC
CAL
AMB
INP
SPAN
ZERO
OUT
OPNO
1, 2
ZERO
SPAN
VER 1
