UNIVERSAL TRANSMITTER UT-94
REF NO: m98A/om/101
Issue NO: 15
User’s Manual Page 5 of 25
2. Installation
2.1 Environment:
Caution: Do not install the unit where it is subjected to continuous vibration.
Do not subject the unit to physical impact.
2.2 Mounting:
The unit can be snapped onto all DIN rails according to EN 60715. The device must be mounted
horizontally (input terminal blocks facing downwards)
2.3 Installation Dimensions:
To ensure sufficient convection, a minimum spacing of 3 cm is required.
1) Place the module with the DIN rail guide way on the bottom edge of the DIN rail and then snap
it downwards.
2) The housing is mounted on the DIN rail by swiveling it into place.
3) As air vents are provided on the top and bottom part of the unit, the (horizontal) mounting
arrangement allows good vertical air circulation.
Vertical mounting arrangement of multiple units must be avoided.
2.4 Removal:
Release the snap-on catch using a screwdriver and then detach the module from the bottom edge of
the DIN Rail.
