WARNING.
InstallationofallgasappliancesMUSTbecarriedoutonlybyanAuthorisedInstaller.
Theheatermustbeinstalledaccordingtotheseinstructionsandincompliancewithall
relevant building, gas-fitting, electrical and other Statutory Regulations (e.g. AS 5601
(AG-601),NZS5261).Anyshortcomingsintheapplianceandflueinstallationwillbethe
responsibility of the installer, and Masport Ltd will not be accountable for any such
failingsortheirconsequences.
Theguardisfittedtothisappliance(Australiaonly)toreducetheriskoffireorinjury
fromburnsandnopartofitshouldbepermanentlyremoved.Fortheprotectionofyoung
childrenortheinfirm,asecondaryguardisrequired.
Theseappliancesmustnotbeinstalledinmobilehomes.
WerecommendthatyouhaveyourheatercheckedyearlybyanAuthorisedTechnician.
BEFORE INSTALLATION COMMENCES, check the data plate on the rear of the
heatercabinettoverifythatitisthecorrecttypetosuityourgasandalsothatthegas
consumptionrateiscorrectforyourapplication.
CONTENTS:-
OPERATINGINSTRUCTIONS............ 2,3,4,5
Cleaninginstructions..................................... 6
INSTALLINGINSTRUCTIONS....................... 6
Heaterdimensions......................................... 6
Minimuminstallationclearances.................... 7
Positioningtheheater.................................... 7
INSTALLINGPROCEDURE............................ 7
Shims............................................................ 7
Gas............................................................... 7
Thermostats.................................................. 8
Gaspressureadjustments.......................... 8,9
Fan............................................................... 9
Emberplacement .......................................... 9
Flue.............................................................. 9
Seismicrestraint.......................................... 10
Testfiring................................................... 10
MAINTENANCEINSTRUCTIONS ............... 11
Logpositions.............................................. 11
Accesspoints.............................................. 11
Glassremovalandassembly........................ 12
Removingtheburners................................. 12
Routinemaintenance................................... 13
Fanwiringdiagram(exceptECS) ............... 13
ECSwiringdiagrams .................................. 14
Troubleshooting................................... 15,16
AnnualServiceRecord ............................... 17
THISBOOKCONTAINSIMPORTANTINFORMATION.
ITMUSTBELEFTWITHTHEPURCHASERTOBE
KEPTINASAFEPLACEFORFUTUREREFERENCE.
1
