Masport BALTIMORE STD NG - Operating Instructions

OPERATINGINSTRUCTIONS
DONOTPLACEARTICLESONORAGAINSTTHISAPPLIANCE.
DONOTUSEORSTOREFLAMMABLEMATERIALSNEARTHISAPPLIANCE.
DONOTSPRAYAEROSOLSINTHEVICINITYOFTHISAPPLIANCEWHILEITISINOPERATION.
LIGHTINGANDRUNNINGTHEFIRE:-
•Openthegassupplyvalvebehindtheappliance,iffitted.
CAUTION:Ifthemainburnerhasbeenalight,waittwotothreeminutesto allowittocoolbeforere-
lightingit.
STDMODELS:-
•Pressdownonthecontrolknobatthetopoftheheaterandturnitslowlyanticlockwise.Thepiezoigniter
willclickasasparkjumpsacrosstheterminalsatthepilotlight.Itmaybenecessarytorepeatthisanumber
oftimesbeforethepilotignitesifthereisairinthepilotlightpipeline.
•Keepholdingthecontrolknobdownfor15to30secondsafterignition.Releasethepressureonthecontrol
knob–thepilotshouldremainalightwhentheknobrises.
•Turnthecontrolfullyanticlockwisetothe‘HIGH’positionandthefirewilllightatfullheat.Theremaybe
astrongsmellthefirsttimethelogsarefiredbutthiswillsoondisappear.
•Aftertenminutes,setthecontroltogivethedesiredheatoutput.
•Atthisstageyoumayturnonthefanbyrotatingthefanswitchineitherdirection.Theswitchgivesthree
speedsandhasan‘off’position.
ACCMODELS:-
Thesecanbeinthreeconfigurations.Theymaybeusedassupplied,ortheymaybefittedwitheithera
batteryoperatedwall-mountedthermostatwhichiswireddirectlytotheheater,orathermostatcontained
inaportableremotecontrol.Withthelatteroption,areceiverismountedonthestovepedestal(oneither
side,attherear,facingforward)tosensethesignalfromtheremotecontrol.Theremotecontrolisbattery
powered, and the receiver requires a 240v AC power source. (Instructions for fitting these optional
thermostatsaresuppliedwiththem.)
LIGHTINGTHEPILOT(ACCmodels):-Note:Toavoidtheriskofbackburning,donotattempttore-light
thefirelessthanthreeminutesafterithasbeenextinguished.
TheprocedureforlightingthepilotisthesameforallthreeACCversions—
•TurntheHI-LO control knob fully anti-clockwise to the HI position. Push down and turn the PILOT
controlknobanti-clockwisetothe‘PILOT’position.PressandholdthePILOTcontrolknobdownfirmly.
The battery igniter will generate a continuous spark across the terminals at the pilot light. It may be
necessarytoholdthecontrolknobdownforsometimebeforethepilotignitesifthereisairinthepilot
lightpipeline.IfthereisnosparkwhenthecontrolknobishelddowninthePILOTposition,checkthe
batteryintheignitionmodule.Itismountedunderthecoverofthesmallblackplastichousingmountedon
thebackoftheheater.OneAAalkalinecellisrequired.
•Keep holdingthecontrolknobdownfor15secondsafterthepilotignites.Releasethepressure onthe
controlknob–thepilotshouldremainalightwhentheknobrises.
•Turnthecontrolknobfullyanticlockwisetothe‘ON’position.Notethatthemainburnerwillnotlightuntil
atleastthirtysecondsafterthepilotislit.
TURNINGONTHEMAINBURNER(ACCmodels):-
Whennothermostatisfitted–
•Pushdownandturnthecontrolknobfullyanticlockwisetothe‘ON’positionandthefirewilllightatfull
heat.Theremaybeastrongsmellthefirsttimethelogsarefiredbutthiswillsoondisappear.
2
