Mastech MAS830L User Manual

Introduction
The instrument of this series is a small hand-held 3 1/2 digital
multimeter featuring stable, highly reliable and anti-drop
performance. It is provided with a LCD display of 15 mm
height for clear reading. The circuit design takes LSI double
integral A/D converter as its core under the protection of an
overload protection circuit, making it a superior and handy
instrument. It can be used to measure DC and AC voltage, DC
current, resistance, diodes, transistors, temperature and for
in-circuit continuity test.
Measurement features of the types of this series:
Features
MAS
830L
MAS
830
MAS
830B
MAS
838
Alternating Voltage
measurement V~




Direct Voltage
measurement V




Direct Current
measurement A




Resistance
measurement 




Diode measurement




hFE test




Continuity checking with
buzzer



Data hold




Backlight

1

Mastech MAS830L Specifications

General

DC Voltage Range	200mV/2V/20V/200V/600V
AC Voltage Range	200V/600V
Resistance Range	200Ω/2kΩ/20kΩ/200kΩ/2MΩ
Continuity Buzzer	Yes
Diode Test	Yes
Transistor Test	Yes
Power Supply	9V battery
Display	LCD
DC Current Range	200μA/2mA/20mA/200mA/10A
Dimensions	138mm x 69mm x 31mm
