Mastech MAS838 - TRANSISTOR Hfe TEST

-5-
TRANSISTOR hFE TEST (0-1000)
Range Test Range Test Current Test Voltage
NPN & PNP 0-1000 Ib=10μA Vce=3V
RESISTANCE
Range Resolution Accuracy
200Ω 0.1Ω ±0.8% of rdg ± 3 digits
2kΩ 1Ω ±0.8% of rdg ± 2 digits
20kΩ 10Ω ±0.8% of rdg ± 2 digits
200kΩ 100Ω ±0.8% of rdg ± 2 digits
2MΩ 1kΩ ±1.0% of rdg ± 2 digits
Maximum Open Circuit Voltage: 3.2V
Overload Protection: 250V dc or rms. ac for all ranges.
TEMPERATURE
Range Resolution Test Range Accuracy
℃ 1℃
-20℃ to 0℃
-0℃ to 400℃
400℃ to 1000℃
±10% of rdg ± 2digits
±1.0% of rdg ± 3digits
±2.0% of rdg
TEMPERATURE
Range Resolution Test Range Accuracy
°F 1 °F
-4°F to 32°F
32°F to 752°F
752°F to 1832°F
±10% of rdg ± 2digits
±1.0% of rdg ± 3digits
±2.0% of rdg
OPERATING INSTRUCTIONS
DC VOLTAGE MEASUREMENT
1.
2.
3.
4.
Connect the red test lead to the “V.Ω.mA” jack and the
black lead to the “COM” jack.
Set rotary switch at desired DCV position. If the voltage
to be measured is not known beforehand, set range
switch at the highest range position and then reduce it
until satisfactory resolution is obtained.
Connect test leads across the source or load being
measured.
Read voltage value on the LCD display along with the
polarity of the red lead connection.
