Mastech MS8233E - 4 Specification; General Specification

- 5 -
3-3. Display indicators
Number
Indicator
Meaning
1
DC voltage or current
2
AC voltage or current
3
Diode
4
MAX
Maximum value
5
HOLD
Data hold
6
Low battery indicator
7
MKΩ
Ω KΩ MΩ is unit of resistance
8
℃/℉
The unit of temperature
(℃: Centigrade; ℉: Fahrenheit)
9
µmVA
mV ,V is unit of voltage
µA, mA, A is unit of current
10
－
Indicate negative reading
- 6 -
Fig. 2 LCD
4．Specification
4-1. General Specification
● Auto ranging DMM , that full scale is 2000 counts
● Display : 3 1/2 digit LCD display..
● Over load protection: Used the PTC protection circuit for Resistance,
temperature
● AC electric field detection function(NCV function)
● DATA HOLD function
● MAX value hold function
● Back Light
● Low battery indication
- 7 -
