Mastech MS8233E - Electrical Specification

● Auto Power- OFF. : If the meter is idle for 15 minutes (idle time), the meter
automatically turns the power off. After auto power-off, pushing any of the push
button or changing the rotary switch can turn on the meter again.
NOTE: （1） After auto power off in the AC mode, if changing the rotary
switch to the DC mode, the Re-power on if disabled.
(2) The meter enters sleep mode after quto power off. If press
“HOLD” push button to re-power on in the sleep mode, the auto
power off function is disabled.
● Operating temperature & Humidity: 0 ~ 40℃ (32 ~104 ℉) & < 80% RH
● Storage temperature & Humidity: -10 ~ 50℃ (14 ~ 122 ℉) & <70%RH
● Power Supply: 9V Battery(6F22 or 1604A Type) x 1pc.
● Safety Class: IEC 61010-1, CAT II 600V.
● Dimension (L x W x H) & Weight: 140 x 67 x 30mm, Approx. 112g
Accessary: 1. K-type temperature probe[P3400]----- 1pc
2. User’s Manual ---------------------------- 1pc
3. Test lead ---------------------------- 1set
4. 9V Battery --------------------------- 1pc
4-2. Electrical Specification ( at 23±5℃; <75% RH)
4.2.1 DC Voltage
Range
Resolution
Accuracy
200mV
0.1mV
±（0.5% rdg + 2dgt）
2V
0.001V
20V
0.01V
200V
0.1V
600V
1V
±（0.8% rdg + 2dgt）
- 8 -
* Over load protection: SG(Spark Gap) used to protect that the voltage
overred 1500V
4.2.2 AC Voltage
Range
Resolution
Accuracy
2V (40Hz-400Hz)
0.001V
±（0.9% rdg + 3dgt）
20V (40Hz-400Hz)
0.01V
200V (40Hz-400Hz)
0.1V
600V (40Hz-200Hz)
1V
±（1.2% ）rdg + 3dgt
* SG(Spark Gap) used to protect High voltage that is
over 1500V.
4.2.3 Resistance
Range
Resolution
Accuracy
200Ω
0.1Ω
±（0.8% rdg + 2dgt）
2kΩ
0.001kΩ
20kΩ
0.01kΩ
200kΩ
0.1kΩ
2MΩ
0.001MΩ
±（1.0% rdg + 2dgt）
20MΩ
0.01MΩ
4.2.4 Diode check
Range
Resolution
Function
0.001V
Will display the forward drop voltage.
* Operating current：about 1mA
* Open circuit voltage：about 1.48V
- 9 -
