14 - TECHNICAL FEATURES
Technical Features 1000 2000 3200 5000
Output power (1KHz - 1% THD) (Note 1)
Stereo 2 Ohm 480 W 980 W 1510 W 2600 W
Stereo 4 Ohm 325 W 700 W 1150 W 1750 W
Stereo 8 Ohm 190 W 480 W 720 W 950 W
Stereo 16 Ohm 100 W 270 W 390 W 520 W
Bridged 4 Ohm 960 W 1960 W 3020 W 5200 W
Bridged 8 Ohm 650 W 960 W 2300 W 3500 W
Frequency response (Note 2) 20Hz - 30KHz (-3dB)
Input impedance > 15KOhm
Sensitivity (Note 3) 1,2 V +4dBm
Harmonic distortion + Noise 0,08% 0,08% 0,08% 0,10%
Signal/Noise ratio > 102 > 104 > 107 > 108
Crosstalk > 65dB > 65dB > 65dB > 70dB
Damping Factor > 300 > 300 > 350 > 350
Supply AC 230V 50 / 60 Hz
Max. Power consumption (Note 4) 6 A 8 A 10 A 12 A
Size (H x W x D) 88x44 2x454 mm 132x44 2x454 mm
Net weight 11,46 Kg 12 Kg 19,8 Kg 20 Kg
Note 1: Continuous burst tone 20 ms (0 dB) / 480 ms (-20 dB) in accordance with EIA RS-490 and IEC 60268-3 (IHF A-202)
Note 2: Internally limited by subsonic and ultrasonic active filters
Note 3: Internally variable through resistor-jumper from 0,775V to 2,40V
Note 4: Musical program - Switch breaker limiter
All specifications and features are subject to change without prior notice. JAN 2002
If you follow the instruction manual and recommendations, we are sure that this
amplifier will always perform within the predetermined parameters, ensuring its long
life and total efficiency.
15 - CERTIFICATE OF WARRANTY
The Conditions and Observations for the application of this Contract of
Warranty are for all the territories of the Spanish State.
For other countries, the specifications of each country must be
complied with, as only the Representative or National importer
themselves can be held responsible for warranty terms.
For any claim of a Legal type, only the Ordinary Courts corresponding
to the city of Terrassa (Barcelona-Spain) will be valid.
Please follow the instructions on the last page of this manual.
