13
ASSEMBLY INSTRUCTIONS
CL
EA
EB
EC
CJ
BK
a. Assemble the Left and Right Tracks (CK and
CL) for the Grease Tray (CJ), as shown in gures
A-C.
b. Insert the Grease Tray (CJ) into the opening of
the Upper Back Panel (BK).
YOU WILL NEED:
11
X 2
12
Close up, front
Close up, back
Back view
A
B
C
D
CL
CL
CK
CK
CI
CK
