HARDWARE CONTENTS
1/4-20 x 1/2 in.
Screw
Qty. 26
BB
B
1/4-20 x 3/8 in.
Screw
Qty. 23
5/32-32 x 3/8 in.
Screw
Qty.16
1/4-20 Lock
Washer
Qty. 22
1/4-20 x 5/16 in.
Screw
Qty.10
7
Before beginning assembly of product, make sure all parts are present. Compare
parts with package contents list and hardware contents list. If any part is
missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 40 minutes by two people
Tools Required for Assembly: Phillips Screwdriver (not included).
PREPARATION
AA Battery
Allen Wrench
AA BB CC DD EE
FF
GG
To Next Page
