Motor
No Load Speed
Double Insulated
Blade
Laser
3800 RPM
120 V~ 60 Hz 15A
Yes
12 in. x 1 in. 48T Carbide-tipped
Wavelength: 650 nm, Max. Output<1 mw Class II
LED Light Yes
Saw body sliding range 0-8 3/4 in.
Bevel range -48°-48°
Miter range 0°-52° Left and 0°-60° Right
Max. Cutting Capacity
Crosscut Miter 0° / Bevel 0° 14 in. x 4 in.
Miter 45° Right & Left / Bevel 0° 10 in. x 4 in.
Miter 0° / Bevel 45° Left 14 in. x 2 in.
Miter 0° / Bevel 45° Right 14 in. x 1 in.
45° Miter & 45° Bevel Left 10 in. x 2 in.
45° Miter & 45° Bevel Right 10 in. x 1 in.
Miter/Bevel Positive Stop Angles
Miter Detent Stops 0°, 15°, 22.5°, 31.6°, 45° (Left)
0°, 15°, 22.5°, 31.6°, 45°, 60° (Right)
Bevel Positive Stops 0°, 22.5°, 33.9°, 45° (Left & Right)
Weight 60.5 lbs (27.5 kg)
Page 11
SPECIFICATIONS
