Page 20
ASSEMBLY
STORAGE (FIG. 11)
Power cord
For convenience and to prevent damage to the power cord
when the miter saw is being transported or in storage.
• Wrap the power cord (A) onto the storage clips (B) when
saw is not in use.
Blade wrench
The storage area (C) for the blade wrench (D) is located in
the left side of the rear carrying handle.
FIG. 11
WARNING:
• To avoid injury, never use the saw without the cover plate securely in place. It keeps the arbor bolt from falling out if it
accidentally loosens and helps prevent the spinning blade from coming off the saw.
• Make sure the anges are clean and properly arranged. Lower the blade into the lower table and check for any contact
with the metal base or the miter table.
A
C
D
B
D
B
C
