Step 6: Fit in the mounting plate rubber
1
The door senor cable goes through the hole in the middle.
2
The keypad cable goes through the rectangle hole on the right.
1
2
11
2
1
Tape the sensor on the door.
Fasten the sensor onto the mounting plate.
2
Step 5: Install the door sensor
Ensure the sensor is close to the frame.
