Master Lock D1000 - Installation

Installation
4
2
1
3
4
4
Step 1: Install the deadbolt
(Skip this step if using original deadbolt)
1
Adjust the bolt length and make sure the “+” hole of deadbolt in the middle of the door hole.
2
Twist the”+”and ensure the plate line up the bolt.
3
Deadbolt must be in retracted position.
4
Screw: Bolt screw *2
