Parts List
# MHP-135-KFA MHP-190-KFA MHP-215-KFA
1 Fuel Tank Assembly 70-002-0610 70-002-0620 70-002-0620
2 Drain Plug 70-002-0105 70-002-0105 70-002-0105
3 Fuel Gauge Assembly 70-007-0210 70-007-0210 70-007-0215
4 Fuel Filter Assembly 70-003-0200 70-003-0200 70-003-0200
5 Fuel Cap 70-006-0125 70-006-0125 70-006-0125
6 Power Cord 70-034-0200 70-034-0200 70-034-0200
7 Power Switch 70-038-0100 70-038-0100 70-038-0100
8 Electronic Fuel Gauge Assembly 70-007-0450 70-007-0450 70-007-0450
9 Thermostat Control Knob 70-031-0130 70-031-0130 70-031-0130
10 Lower Shell 70-001-2315 70-001-2325 70-001-2325
11 Air Line 70-035-0520 70-035-0525 70-035-0530
12 Thermostat Limit Control 70-019-0100 70-019-0100 70-019-0200
13 Combustion Chamber Assembly 70-011-0520 70-011-0525 70-011-0530
14 Photocell Bracket 70-010-0101 70-010-0101 70-010-0101
15 Fuel Line 70-036-0520 70-036-0525 70-036-0530
16 Photocell Assembly 70-016-0100 70-016-0100 70-016-0100
17 Burner Head Assembly 70-014-0300 70-014-0400 70-014-0500
18 Nozzle Kit 70-015-0300 70-015-0400 70-015-0500
19 Spark Plug Kit 70-052-0200 70-052-0200 70-052-0200
20 Motor and Pump Assembly 70-020-0555 70-020-0560 70-020-0560
21 Motor 70-021-0510 70-021-0520 70-021-0520
22 Pump Body 70-020-0101 70-020-0101 70-020-0401
23 Rotor Kit 70-022-0100 70-022-0100 70-022-0200
24 Vein 70-022-0230 70-022-0230 70-022-0230
25 Output Filter 70-023-0100 70-023-0100 70-023-0100
26 Pump Adjustment Kit 70-055-0100 70-055-0100 70-055-0100
27 Lint Filter 70-054-0102 70-054-0102 70-054-0102
28 Intake Filter 70-054-0101 70-054-0101 70-054-0101
29 End Filter Cover 70-020-0103 70-020-0103 70-020-0103
30 Nipple 70-014-0104 70-014-0104 70-014-0104
31 Capacitor 70-020-0200 70-020-0201 70-020-0201
32 Fan Assembly 70-024-0300 70-024-0400 70-024-0400
33 Ignitor 70-037-0300 70-037-0300 70-037-0300
34 Right Side Cover 70-008-0775 70-008-0780 70-008-0780
35 Left Side Cover 70-009-0515 70-009-0520 70-009-0525
36 Fan Guard 70-016-0715 70-016-0715 70-016-0715
37 Main PCB 70-027-0870 70-027-0875 70-027-0875
38 Fuse 70-027-0101 70-027-0101 70-027-0101
39 Clip Nut 70-001-0105 70-001-0105 70-001-0105
40 Upper Shell 70-001-2310 70-001-2320 70-001-2320
41 Y Bracket 70-043-0561 70-043-0561 70-043-0561
42 Y Bracket 70-043-0566 70-043-0566 70-043-0566
43 Handle Grommet 70-043-0570 70-043-0570 70-043-0570
44 Air Pressure Gauge 70-025-0100 70-025-0100 70-025-0100
45 Cord Bushing 70-033-0200 70-033-0200 70-033-0200
46 Front Handle 70-043-0520 70-043-0520 70-043-0525
47 Rear Handle 70-043-0530 70-043-0530 70-043-0535
48 Wheel Support Frame 70-043-0505 70-043-0510 70-043-0510
49 Wheel Axle 70-043-0550 70-043-0550 70-043-0555
50 Wheel 70-041-0520 70-041-0520 70-041-0520
51 Wheel Nut 70-041-0550 70-041-0550 70-041-0550
52 Spacer 70-041-0108 70-041-0108 70-041-0108
53 Cord Wraps 70-032-0200 70-032-0200 70-032-0200
54 Top Cover 70-009-0550 70-009-0550 70-009-0550
55 Filter Kit 70-054-0100 70-054-0100 70-054-0100
56 End Pump Cover 70-020-0102 70-020-0102 70-020-0102
