NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
© 2014, Pinnacle Products International, Inc. Kerosene Forced Air Heater User’s Manual
4
- Remove the heater and all packaging
materials from the shipping carton.
Tools Needed:
- Phillips Head Screw Driver
- 8 mm open end wrench
- 19 mm open end wrench
Assembly Instructions
Models: MHP-135-KFA / MHP-190-KFA / MHP-215-KFA
What’s In The Box
50 mm Screws (8) 8 mm Nuts (12) Tires (2)
Y-Bracket (2) Axle Nuts (2)
Spacers (2)
Spare Drain Plug (1)
Missing Parts? Please Call 800-641-6996 For Assistance
Front Handle
Axle
Rear Handle
Wheel Support Frame
Tip: Be sure to remove the axle from the
side of the Styrofoam packaging.
Tip: Use a power screwdriver and
locking wrench for easier assembly.
Cord Wraps
