Deluxe Fusion BT Stereo Option –
Location of Controls
1.1 DIGITAL MEDIA LOCKER CONTROLS
1. Open/Close Latch & Protective Door
2. Power ON/OFF Button
3. Water/Dust Protection Inner Gasket
4. 3.5mm Aux Input for MP3 Devices
5. Power ON/OFF LED
6. Security Strap for digital media devices
7. USB Connector
8. Door Control Keypad
9. LED Mode Indicator
10. Back lighting
11. Cable Storage Tray
2
9
11
10
6
7
3
5
4
8
1
