Symptom: Insufficient Brine draw
Possible Cause Solution
Partially clogged injector or injector
screen
Inspect and clean injector and/or
injector screen assembly.
Restricted flow rate in brine line Check flow rate capabilities of the
safety float/aircheck assembly.
Insufficient water pressure Increase water pressure above 25
psig (172kPa) minimum.
Excessive back pressure on
injector due to elevated drain line
Reduce drain line elevation to height
of valve.
Damaged piston assembly Inspect and if damaged replace the
piston assembly.
Control valve has incorrect program
values.
Reset values.
Partially restricted drain line Remove restriction.
Symptom: Insufficient Refill to Brine Tank
Possible Cause Solution
Control valve has incorrect program
values.
Reset values.
Restricted flow rate in brine line Check flow rate capabilities of the
safety float/aircheck assembly.
Problem: Leak to Drain
Possible Cause Solution
No flow control installed in drain
line.
Install drain line flow control.
Insufficient water pressure. Increase water pressure above 25
psig (172kPa) minimum.
