Master MH-150T-DFV User's Manual And Operating Instructions

NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
© 2014, Pinnacle Products International, Inc. Dual Fusion Forced Air Heater User’s Manual
13
Parts List
Item # Description MH-150T-DFV MH-220T-DFV
1
Front Shell 70-001-5100 70-001-5105
2
3 Upper Shell 70-001-5010 70-001-5010
4 Combustion Chamber 70-011-1000 70-011-1010
5 Control PCB 70-027-1000 70-027-1000
6 Power PCB Case 70-027-1250 70-027-1250
7 PCB Lead Wire 70-027-1020 70-027-1020
8 Nozzle 70-015-1000 70-015-1010
9 Air Dispenser 70-063-1000 70-063-1000
10 Burner Head 70-014-1000 70-014-1000
11 Fuel Line Nipple 70-014-1100 70-014-1100
12 Spark Plug 70-052-1000 70-052-1000
13 Limit Control 70-019-1000 70-019-1000
14 Limit Control Bracket 70-019-1010 70-019-1010
15 Photocell 70-016-1000 70-016-1000
16 Photocell bracket 70-016-1010 70-016-1010
17 Air Draft Tube 70-300-0001 70-300-0010
18 Duct Bracket 70-300-0020 70-300-0020
19 Sirroco Fan 70-060-0001 70-060-0001
20 Duct Assembly 70-300-0100 70-300-0100
21 Motor Assembly 70-020-1000 70-020-1000
22 Motor Supporter 70-020-1010 70-020-1010
23 Blower Fan 70-024-1000 70-024-1000
24 Fan Guard 70-016-1000 70-016-1000
25 Ignitor 70-037-1000 70-037-1000
26 Side Cover 70-008-1100 70-008-1100
27 Power Cord 70-034-1000 70-034-1000
28 Return Fuel Line 70-036-2100 70-036-2100
29 Intake Fuel Line 70-036-2000 70-036-2000
30 Fuel Pump 70-400-0100 70-400-0100

Master MH-150T-DFV Specifications

General

Brand	Master
Model	MH-150T-DFV
Category	Heater
Language	English
