NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
© 2014, Pinnacle Products International, Inc. Dual Fusion Forced Air Heater User’s Manual
Operation
Starting the Heater: (Ignition)
1. Fill the tank with kerosene or other approved
fuel until needle on fuel gauge points to “F”.
2. Replace fuel cap and tighten firmly.
3. Connect the heater to a three prong
(grounded) power source. You must use a
three prong (grounded) extension cord that
is at least 6 feet long and is a minimum of 14
AWG rating.
4. Press the power button to power on the
heater.
5. Select BTU output setting using BTU HI / LO
buttons.
6. Select desired temperature using temperature
HI / LO buttons.
7. The heater will ignite once the temperature
setting is higher than the ambient
temperature in the space.
NOTE: If if the heater still does not ignite,
refer to“Troubleshooting Guide” on page 11.
Stopping / Restarting Heater:
- To stop the heater, move the power switch to
the “Off” position and unplug the power cord.
- To restart the heater; wait 10 seconds and
follow ignition steps.
Control Panel:
7
TIP: If the heater does not ignite; press
power button to power off the heater,
check steps 1-3 above and press power
button to power ON the heater.
TIP: If the heater does not ignite, the
thermostat may be set too low. Increase
the temperature to a higher setting until the
heater ignites.
HI
(BTU)
LO
(BTU)
HI
(Temp)
LO
(Temp)
Power
On/Off
Figure 4
