STEP 9.
Step 9 requires assistance.
Get a helper!
Align grill lid (1) with grill body (4) as
shown. Secure grill lid (1) to grill body
(4) using carriage bolt (G).
Repeat step on opposite end.
4
1
G
STEP 10.
Insert temperature gauge (17)
through slotted hole in grill lid (1).
Secure by turning temperature guage
(17) and lock into place with retainer
ring.
17
1
9
10
STEP 12.
Attach smoke stack (15) to right side
of grill lid (1) and secure with phillips
head screws (F) as shown.
STEP 11.
Secure handle (16) to grill lid (1)
using flat washer (D), lock washer (C)
and hex flange nut (B).
B
D
C
1
15
F
16
1
