distúrbios irradiados de RF são controlados. O cliente ou usuário do aparelho pode ajudar a evitar a interferência eletromagnética
por manter uma distância mínima entre equipamentos de comunicação RF portáteis ou móveis (transmissores) e o aparelho
conforme recomendado abaixo, de acordo com a energia máxima de saída do equipamento de comunicação.
POTÊNCIA MÁXIMA NOMINAL
DE SAÍDA DO TRANSMISSOR
W
DISTÂNCIA DE SEPARAÇÃO DE ACORDO COM A FREQÜÊNCIA DO TRANSMISSOR m
150 kHz a 80 MHz
d = 1,2
Symbol Descriptions
Caution
Please read the instructions for use
Battery Recycling
BF type applied part
Paper Recycling
Stand-by
IP22
Classification for water ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below.The customer or the user of the THD2FE
should assure that it is used in such an environment.
Emissions test
Compliance
Electromagnetic environment – guidance
(for home healthcare environment)
RF emissions
CISPR 11
Group 1
The THD2FE uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
RF emissions
CISPR 11
Class B
The THD2FE is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Immunity test
IEC 60601 test level
Compliance level
Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30%
Power frequency(50, 60 Hz)
magnetic field IEC 61000-4-8
30 A/m
50 Hz or 60 Hz
30 A/m
50 Hz and 60 Hz
The THD2FE power frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Immunity test
IEC 60601 test level
Compliance
level
Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2
d = 1,2 80MHz to 800 MHz
d = 2,3 800MHz to 2,7 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey,
a
should be less than the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment marked with the following
symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM
radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the THD2FE is used exceeds the
applicable RF compliance level above, the THD2FE should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the THD2FE.
Recommended separation distances between
portable and mobile RF communications equipment and the THD2FE
80 MHz a 800 MHz
d = 1,2
Symbol Descriptions
Caution
Please read the instructions for use
Battery Recycling
BF type applied part
Paper Recycling
Stand-by
IP22
Classification for water ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below.The customer or the user of the THD2FE
should assure that it is used in such an environment.
Emissions test
Compliance
Electromagnetic environment – guidance
(for home healthcare environment)
RF emissions
CISPR 11
Group 1
The THD2FE uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
RF emissions
CISPR 11
Class B
The THD2FE is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Immunity test
IEC 60601 test level
Compliance level
Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30%
Power frequency(50, 60 Hz)
magnetic field IEC 61000-4-8
30 A/m
50 Hz or 60 Hz
30 A/m
50 Hz and 60 Hz
The THD2FE power frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Immunity test
IEC 60601 test level
Compliance
level
Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2
d = 1,2 80MHz to 800 MHz
d = 2,3 800MHz to 2,7 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey,
a
should be less than the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment marked with the following
symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM
radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the THD2FE is used exceeds the
applicable RF compliance level above, the THD2FE should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the THD2FE.
Recommended separation distances between
portable and mobile RF communications equipment and the THD2FE
800 MHz a 2,7 GHz
d = 2,3
Symbol Descriptions
Caution
Please read the instructions for use
Battery Recycling
BF type applied part
Paper Recycling
Stand-by
IP22
Classification for water ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below.The customer or the user of the THD2FE
should assure that it is used in such an environment.
Emissions test
Compliance
Electromagnetic environment – guidance
(for home healthcare environment)
RF emissions
CISPR 11
Group 1
The THD2FE uses RF energy only for its internal function. Therefore, its RF emissions are very
low and are not likely to cause any interference in nearby electronic equipment.
RF emissions
CISPR 11
Class B
The THD2FE is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Immunity test
IEC 60601 test level
Compliance level
Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30%
Power frequency(50, 60 Hz)
magnetic field IEC 61000-4-8
30 A/m
50 Hz or 60 Hz
30 A/m
50 Hz and 60 Hz
The THD2FE power frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The THD2FE is intended for use in the electromagnetic environment (for home healthcare) specified below. The customer or the user of the THD2FE
should assure that it is used in such an environment.
Immunity test
IEC 60601 test level
Compliance
level
Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2
d = 1,2 80MHz to 800 MHz
d = 2,3 800MHz to 2,7 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and d is the recommended separation distance in metres
(m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey,
a
should be less than the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment marked with the following
symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM
radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the THD2FE is used exceeds the
applicable RF compliance level above, the THD2FE should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the THD2FE.
Recommended separation distances between
portable and mobile RF communications equipment and the THD2FE
0,01 N/A 0,12 0,23
0,1 N/A 0,38 0,73
1 N/A 1,2 2,3
10 N/A 3,8 7,3
100 N/A 12 23
Para transmissores especificados numa potência de saída máxima não listada acima, a distância de separação
recomendada d em metros (m) pode ser estimada usando a equação aplicável à frequência do transmissor, onde P é a
potência nominal máxima de saída do transmissor em watts (W) de acordo com o fabricante do transmissor.
NOTA 1 A 80 MHz e 800 MHz, a distância de separação para a faixa de mais alta frequência é aplicável.
NOTA: 2 Estas instruções podem não se aplicar em todas as situações. A propagação eletromagnética é afetada pela
absorção e reflexão das estruturas, objetos e pessoas.
COMUNICAÇÃO DO FABRICANTE – ESPECIFICAÇÕES DOS TESTES DE IMUNIDADE ELETROMAGNÉTICA PARA A
IMUNIDADE DAS PORTAS DE CAIXAS DOS EQUIPAMENTOS DE RF DE COMUNICAÇÃO SEM FIO
Aparelho destinado ao uso em ambientes com emissões eletromagnéticas (para cuidados domésticos de saúde), como
especificado abaixo. O cliente ou usuário deverá assegurar que o aparelho seja utilizado neste ambiente.
FREQUÊNCIA
DE TESTE
(MHZ)
FAIXA
A)
(MHZ)
SERVIÇO
A)
MODULAÇÃO
B)
POTÊNCIA
MÁXIMA
(W)
DISTÂNCIA
(M)
NÍVEL DO
TESTE DE
IMUNIDADE
(V/m)
NÍVEL DE CONFORMI-
DADE (V/M)
(PARA CUIDADOS
DOMÉSTICOS DE
SAÚDE)
385
380 -
390
TETRA 400
Modulação por
pulsos b) 18Hz
1,8 0,3 27 27
450
430 -
470
GMRS 460,
FRS 460
FM c) ±5 kHz
desvio 1 kHz,
senoidal
2 0,3 28 28
710
704 -
787
LTE Band 13,17
Modulação por
pulsos
b) 217 Hz
0,2 0,3 9 9745
780
810
800 -
960
GSM 800/900,
TETRA 800, iDEN
820, CDMA 850, LTE
Band 5
Modulação por
pulsos
b) 18 Hz
2 0,3 28 28
870
930
1720
1700 -
1990
GSM 1800; CDMA
1900; GSM 1900;
DECT; LTE Band 1, 3,
4, 25; UMTS
Modulação por
pulsos
b) 217 Hz
2 0,3 28 28
1845
1970
2450
2400 -
2570
Bluetooth, WLAN,
802.11 b/g/n, RFID
2450, LTE Band 7
Modulação por
pulsos
b) 217 Hz
2 0,3 28 28
5240
5100 -
5800
WLAN 802.11
a/n
Modulação por
pulsos
b) 217 Hz
0,2 0,3 9 95500
5785
NOTA Caso seja necessário para atingir o NÍVEL DO TESTE DE IMUNIDADE, a distância entre a antena transmissora e
o EQUIPAMENTO ou SISTEMA ME pode ser reduzida a 1 m. Essa distância de teste de 1 m é permitida pela norma IEC
61000-4-3.
a) Para alguns serviços, estão incluídas apenas as frequências de uplink.
b) A portadora deve ser modulada utilizando-se um sinal de onda quadrada, com ciclo de trabalho de 50%.
c) Como alternativa à modulação FM, pode-se usar modulação por pulsos em 50% a 18 Hz (embora não represente a
modulação real, seria o pior caso).
