37www.mastercool.com
MULTIFUNKTIONELL INFRARÖD TERMOMETER FÖR SJUKVÅRD/YTOR
SPECIFIKATIONER:
• Temperaturmätområde:
Pannläge: 34 till 42,2°C (93,2 till 108°F)
Ytläge: -22 till 80°C (-7,6 till 176°F)
• Operativt temperaturområde: 10 till 40°C (-7,6 till 176°F),
15% till 85% RH
• Förvaringstemperatur: förvara vid rumstemperatur mellan
-20 till 50°C ( -4 till 122°F), RH < 85 %
• Temperatur vid transport ska vara mindre än 70°C (158°F), RH < 95%
• Atmosfäriskt tryck: 800 till 1013 hPa
• Precision:
Pannläge: ±0,2 °C (0,4 °F) mellan 35 till 42 °C (95 till 107,6 °F)
(Omgivande temp: 15 till 35°C (9 till 95°F), ±0,5°F (0,3°C) för
annat område Ytläge: ±0,3°C (0,5°F) inom 22 till 42,2°C (71,6 till 108°F),
andra ±4 % eller ±2 °C (4°F) beroende på vad som är störst
• Batteri: AAA x 2 st
• Livslängd batteri: omkring 3 000 kontinuerliga mätningar
• Förväntad livslängd: 4 år
• Blå LED bakgrundsbelysning: sätts på automatiskt efter mätning och stängs av automatiskt efter 5 sekunder
• Kapslingsklassning: IP22
OBSERVERA: Termometern kalibreras vid tillverkning. Kontakta serviceavdelningen om du har frågor om kalibreringsläge,
temperaturmätningarnas noggrannhet eller oväntade händelser.
Varning: Modifiering av denna utrustning är inte tillåtet.
Varning: Doppa inte enheten i några vätskor eller utsätt för direkt fukt.
FUNKTIONER
PANNTEMPERATUR:
Termometern ska inte ersätta ett läkarbesök. Kom också ihåg att jämföra mätresultatet med din vanliga
kroppstemperatur. Tala med en läkare om du har frågor kring din hälsa.
• Se avsnittet ”ANVÄNDA TERMOMETERN” för att få information om hur man mäter
kroppstemperatur.
THD2FE Non-contact Forehead Thermometer
Functions
The thermometer has been designed for home use. It’s not meant to replace a visit to the
doctor. Please also remember to compare the measurement result to your regular body
temperature. Please consult with doctor if you have health concerns.
à Please see the “Use of the thermometer”
section to learn how to measure the body
temperature.
The surface mode shows the actual and unadjusted surface temperature which is different from
the body temperature. It can help you monitor if the object temperature is suitable for the baby
or patient, for example the baby’s milk.
à Please see the “Use of the thermometer” section to learn how to measure
the object
temperature.
If the thermometer detects a temperature ≧99.5°F (or 37.5°C) under forehead mode, three
short beep sound will follow one long beep sound to warn the user for the temperature is above
99.5°F (37.5°C).
There are total 25 sets of measurement condition for body temperature.
à When power on, press the “ON/MEM” button to see the temperature records with icon.
In “Power Off” mode, press and hold the “START” button, then press the “ON/MEM” button for
3 seconds, icon “°F” will be switched to icon “°C”. You can also use the same process to
change the LCD display from °C to °F.
NOTE:
Memory clear and Celsius/Fahrenheit switch are together. When you switch Celsius and
Fahrenheit, the Memory will be cleared.
The device setting with buzzer is on, you can set buzzer on/off under Mute mode.
When power on, press and hold the “ON/MEM” button for 3 seconds. The icon
will flash on
the LCD screen and then release the “ON/MEM” button to set MUTE. Thus you will not hear
beep sounds. You can also use the same process to turn off the Mute function.
NOTE: If keep pressing "ON/MEN" button for 2 seconds after
icon flashing, the device will
be power off WITHOUT setting Mute.
Use of the thermometer
Note: If there is any temperature difference between the places where the device is stored and where you are going to measure, subject and the device should
stay in the same room for at least 15 minutes before measurement.
1. Always make sure the probe lens is clean without any damage and the forehead is clean.
Warning: Choking from swallowing small parts and batteries by children or pets is possible, please keep small parts and batteries at places where
children and pets can’t reach.
2. Power on:
Press the “ON/MEM” button (see figure 1).
3. Measuring body temperature on the forehead:
The Non-contact Clinical Thermometer, Model THD2FE is an infrared thermometer intended
for the intermittent measurement of human body temperature in people of all ages.
At least 11 years old (5 years intensive reading experience), no maximum.
þ Temperature measurement range:
Forehead mode: 93.2~108°F (34~42.2°C)
Surface mode: -7.6~176°F (-22~80°C)
þ Operating temperature range: 50~104°F (10~40°C), 15%~85% RH
þ Storage temperature range: It should be stored at room temperature between -4~122°F
(-20~+50°C), RH≦85%
Transportation temperature shall be less than 158°F (70°C), RH≦95%
þ Atmospheric pressure: 800~1013 hPa
þ Comply with ASTM E1965-98, EN ISO 80601-2-56, IEC/EN60601-1-2(EMC),
IEC/EN60601-1(Safety) standards, ISO10993, RoHS.
þ Accuracy:
Forehead mode: ±0.4
o
F (0.2
°C ) within 95~107.6°F (35~42°C),
±0.5
o
F (0.3
°C ) for other range.
Surface mode: ±0.5°F (0.3°C) within 71.6~108°F (22~42.2°C),
others ±4% or ±4°F (2°C) whichever is greater.
þ Temperature indicator, memory and °F / °C switch function
þ Battery: AAA x 2 pcs
þ Battery life: around 3,000 continuous readings.
þ Expected Service Life: 4 years
þ This thermometer converts the forehead temperature to display its “oral equivalent.”
(according to the result of the clinical evaluation to get the offset value)
þ Blue LED Backlight
Blue LED backlight will be automatically turned on after measurement, and automatically
turned off after 2 seconds.
þ Enclosure Rating: IP22
þ Dimensions: 158.0 x 48.0 x 40.2 mm
þ Weight: 100 grams including battery
The device should not submerge into any liquids and expose it to direct moisture.
There is no gender and age limitation for using the infrared thermometer.
This is not an AP or APG product.
YTTEMPERATUR:
I ytläge visas den faktiska och ojusterade yttemperaturen, vilken skiljer sig från kroppstemperaturen.
• Se avsnittet ”ANVÄNDA TERMOMETERN” för att få information om hur man mäter ett objekts
temperatur.
THD2FE Non-contact Forehead Thermometer
Functions
The thermometer has been designed for home use. It’s not meant to replace a visit to the
doctor. Please also remember to compare the measurement result to your regular body
temperature. Please consult with doctor if you have health concerns.
à Please see the “Use of the thermometer”
section to learn how to measure the body
temperature.
The surface mode shows the actual and unadjusted surface temperature which is different from
the body temperature. It can help you monitor if the object temperature is suitable for the baby
or patient, for example the baby’s milk.
à Please see the “Use of the thermometer” section to learn how to measure
the object
temperature.
If the thermometer detects a temperature ≧99.5°F (or 37.5°C) under forehead mode, three
short beep sound will follow one long beep sound to warn the user for the temperature is above
99.5°F (37.5°C).
There are total 25 sets of measurement condition for body temperature.
à When power on, press the “ON/MEM” button to see the temperature records with icon.
In “Power Off” mode, press and hold the “START” button, then press the “ON/MEM” button for
3 seconds, icon “°F” will be switched to icon “°C”. You can also use the same process to
change the LCD display from °C to °F.
NOTE:
Memory clear and Celsius/Fahrenheit switch are together. When you switch Celsius and
Fahrenheit, the Memory will be cleared.
The device setting with buzzer is on, you can set buzzer on/off under Mute mode.
When power on, press and hold the “ON/MEM” button for 3 seconds. The icon
will flash on
the LCD screen and then release the “ON/MEM” button to set MUTE. Thus you will not hear
beep sounds. You can also use the same process to turn off the Mute function.
NOTE: If keep pressing "ON/MEN" button for 2 seconds after
icon flashing, the device will
be power off WITHOUT setting Mute.
Use of the thermometer
Note: If there is any temperature difference between the places where the device is stored and where you are going to measure, subject and the device should
stay in the same room for at least 15 minutes before measurement.
1. Always make sure the probe lens is clean without any damage and the forehead is clean.
Warning: Choking from swallowing small parts and batteries by children or pets is possible, please keep small parts and batteries at places where
children and pets can’t reach.
2. Power on:
Press the “ON/MEM” button (see figure 1).
3. Measuring body temperature on the forehead:
The Non-contact Clinical Thermometer, Model THD2FE is an infrared thermometer intended
for the intermittent measurement of human body temperature in people of all ages.
At least 11 years old (5 years intensive reading experience), no maximum.
þ Temperature measurement range:
Forehead mode: 93.2~108°F (34~42.2°C)
Surface mode: -7.6~176°F (-22~80°C)
þ Operating temperature range: 50~104°F (10~40°C), 15%~85% RH
þ Storage temperature range: It should be stored at room temperature between -4~122°F
(-20~+50°C), RH≦85%
Transportation temperature shall be less than 158°F (70°C), RH≦95%
þ Atmospheric pressure: 800~1013 hPa
þ Comply with ASTM E1965-98, EN ISO 80601-2-56, IEC/EN60601-1-2(EMC),
IEC/EN60601-1(Safety) standards, ISO10993, RoHS.
þ Accuracy:
Forehead mode: ±0.4
o
F (0.2
°C ) within 95~107.6°F (35~42°C),
±0.5
o
F (0.3
°C ) for other range.
Surface mode: ±0.5°F (0.3°C) within 71.6~108°F (22~42.2°C),
others ±4% or ±4°F (2°C) whichever is greater.
þ Temperature indicator, memory and °F / °C switch function
þ Battery: AAA x 2 pcs
þ Battery life: around 3,000 continuous readings.
þ Expected Service Life: 4 years
þ This thermometer converts the forehead temperature to display its “oral equivalent.”
(according to the result of the clinical evaluation to get the offset value)
þ Blue LED Backlight
Blue LED backlight will be automatically turned on after measurement, and automatically
turned off after 2 seconds.
þ Enclosure Rating: IP22
þ Dimensions: 158.0 x 48.0 x 40.2 mm
þ Weight: 100 grams including battery
The device should not submerge into any liquids and expose it to direct moisture.
There is no gender and age limitation for using the infrared thermometer.
This is not an AP or APG product.
TEMPERATURINDIKATOR:
Om termometern uppmäter en temperatur > 37,5°C (eller 99,5°F) i pannläge hörs tre korta pip följda
av ett långt pip för att varna användaren att temperaturen är över 37,5°C (99,5°F)
THD2FE Non-contact Forehead Thermometer
Functions
The thermometer has been designed for home use. It’s not meant to replace a visit to the
doctor. Please also remember to compare the measurement result to your regular body
temperature. Please consult with doctor if you have health concerns.
à Please see the “Use of the thermometer”
section to learn how to measure the body
temperature.
The surface mode shows the actual and unadjusted surface temperature which is different from
the body temperature. It can help you monitor if the object temperature is suitable for the baby
or patient, for example the baby’s milk.
à Please see the “Use of the thermometer” section to learn how to measure
the object
temperature.
If the thermometer detects a temperature ≧99.5°F (or 37.5°C) under forehead mode, three
short beep sound will follow one long beep sound to warn the user for the temperature is above
99.5°F (37.5°C).
There are total 25 sets of measurement condition for body temperature.
à When power on, press the “ON/MEM” button to see the temperature records with icon.
In “Power Off” mode, press and hold the “START” button, then press the “ON/MEM” button for
3 seconds, icon “°F” will be switched to icon “°C”. You can also use the same process to
change the LCD display from °C to °F.
NOTE:
Memory clear and Celsius/Fahrenheit switch are together. When you switch Celsius and
Fahrenheit, the Memory will be cleared.
The device setting with buzzer is on, you can set buzzer on/off under Mute mode.
When power on, press and hold the “ON/MEM” button for 3 seconds. The icon
will flash on
the LCD screen and then release the “ON/MEM” button to set MUTE. Thus you will not hear
beep sounds. You can also use the same process to turn off the Mute function.
NOTE: If keep pressing "ON/MEN" button for 2 seconds after
icon flashing, the device will
be power off WITHOUT setting Mute.
Use of the thermometer
Note: If there is any temperature difference between the places where the device is stored and where you are going to measure, subject and the device should
stay in the same room for at least 15 minutes before measurement.
1. Always make sure the probe lens is clean without any damage and the forehead is clean.
Warning: Choking from swallowing small parts and batteries by children or pets is possible, please keep small parts and batteries at places where
children and pets can’t reach.
2. Power on:
Press the “ON/MEM” button (see figure 1).
3. Measuring body temperature on the forehead:
The Non-contact Clinical Thermometer, Model THD2FE is an infrared thermometer intended
for the intermittent measurement of human body temperature in people of all ages.
At least 11 years old (5 years intensive reading experience), no maximum.
þ Temperature measurement range:
Forehead mode: 93.2~108°F (34~42.2°C)
Surface mode: -7.6~176°F (-22~80°C)
þ Operating temperature range: 50~104°F (10~40°C), 15%~85% RH
þ Storage temperature range: It should be stored at room temperature between -4~122°F
(-20~+50°C), RH≦85%
Transportation temperature shall be less than 158°F (70°C), RH≦95%
þ Atmospheric pressure: 800~1013 hPa
þ Comply with ASTM E1965-98, EN ISO 80601-2-56, IEC/EN60601-1-2(EMC),
IEC/EN60601-1(Safety) standards, ISO10993, RoHS.
þ Accuracy:
Forehead mode: ±0.4
o
F (0.2
°C ) within 95~107.6°F (35~42°C),
±0.5
o
F (0.3
°C ) for other range.
Surface mode: ±0.5°F (0.3°C) within 71.6~108°F (22~42.2°C),
others ±4% or ±4°F (2°C) whichever is greater.
þ Temperature indicator, memory and °F / °C switch function
þ Battery: AAA x 2 pcs
þ Battery life: around 3,000 continuous readings.
þ Expected Service Life: 4 years
þ This thermometer converts the forehead temperature to display its “oral equivalent.”
(according to the result of the clinical evaluation to get the offset value)
þ Blue LED Backlight
Blue LED backlight will be automatically turned on after measurement, and automatically
turned off after 2 seconds.
þ Enclosure Rating: IP22
þ Dimensions: 158.0 x 48.0 x 40.2 mm
þ Weight: 100 grams including battery
The device should not submerge into any liquids and expose it to direct moisture.
There is no gender and age limitation for using the infrared thermometer.
This is not an AP or APG product.
MINNE:
Det går att registrera 25 mätningar för kroppstemperatur.
• Med enheten påslagen, tryck på ”ON/MEM”-knappen för att se registrerade temperaturer med
symbolen
THD2FE Non-contact Forehead Thermometer
Functions
The thermometer has been designed for home use. It’s not meant to replace a visit to the
doctor. Please also remember to compare the measurement result to your regular body
temperature. Please consult with doctor if you have health concerns.
à Please see the “Use of the thermometer”
section to learn how to measure the body
temperature.
The surface mode shows the actual and unadjusted surface temperature which is different from
the body temperature. It can help you monitor if the object temperature is suitable for the baby
or patient, for example the baby’s milk.
à Please see the “Use of the thermometer” section to learn how to measure
the object
temperature.
If the thermometer detects a temperature ≧99.5°F (or 37.5°C) under forehead mode, three
short beep sound will follow one long beep sound to warn the user for the temperature is above
99.5°F (37.5°C).
There are total 25 sets of measurement condition for body temperature.
à When power on, press the “ON/MEM” button to see the temperature records with icon.
In “Power Off” mode, press and hold the “START” button, then press the “ON/MEM” button for
3 seconds, icon “°F” will be switched to icon “°C”. You can also use the same process to
change the LCD display from °C to °F.
NOTE:
Memory clear and Celsius/Fahrenheit switch are together. When you switch Celsius and
Fahrenheit, the Memory will be cleared.
The device setting with buzzer is on, you can set buzzer on/off under Mute mode.
When power on, press and hold the “ON/MEM” button for 3 seconds. The icon
will flash on
the LCD screen and then release the “ON/MEM” button to set MUTE. Thus you will not hear
beep sounds. You can also use the same process to turn off the Mute function.
NOTE: If keep pressing "ON/MEN" button for 2 seconds after
icon flashing, the device will
be power off WITHOUT setting Mute.
Use of the thermometer
Note: If there is any temperature difference between the places where the device is stored and where you are going to measure, subject and the device should
stay in the same room for at least 15 minutes before measurement.
1. Always make sure the probe lens is clean without any damage and the forehead is clean.
Warning: Choking from swallowing small parts and batteries by children or pets is possible, please keep small parts and batteries at places where
children and pets can’t reach.
2. Power on:
Press the “ON/MEM” button (see figure 1).
3. Measuring body temperature on the forehead:
The Non-contact Clinical Thermometer, Model THD2FE is an infrared thermometer intended
for the intermittent measurement of human body temperature in people of all ages.
At least 11 years old (5 years intensive reading experience), no maximum.
þ Temperature measurement range:
Forehead mode: 93.2~108°F (34~42.2°C)
Surface mode: -7.6~176°F (-22~80°C)
þ Operating temperature range: 50~104°F (10~40°C), 15%~85% RH
þ Storage temperature range: It should be stored at room temperature between -4~122°F
(-20~+50°C), RH≦85%
Transportation temperature shall be less than 158°F (70°C), RH≦95%
þ Atmospheric pressure: 800~1013 hPa
þ Comply with ASTM E1965-98, EN ISO 80601-2-56, IEC/EN60601-1-2(EMC),
IEC/EN60601-1(Safety) standards, ISO10993, RoHS.
þ Accuracy:
Forehead mode: ±0.4
o
F (0.2
°C ) within 95~107.6°F (35~42°C),
±0.5
o
F (0.3
°C ) for other range.
Surface mode: ±0.5°F (0.3°C) within 71.6~108°F (22~42.2°C),
others ±4% or ±4°F (2°C) whichever is greater.
þ Temperature indicator, memory and °F / °C switch function
þ Battery: AAA x 2 pcs
þ Battery life: around 3,000 continuous readings.
þ Expected Service Life: 4 years
þ This thermometer converts the forehead temperature to display its “oral equivalent.”
(according to the result of the clinical evaluation to get the offset value)
þ Blue LED Backlight
Blue LED backlight will be automatically turned on after measurement, and automatically
turned off after 2 seconds.
þ Enclosure Rating: IP22
þ Dimensions: 158.0 x 48.0 x 40.2 mm
þ Weight: 100 grams including battery
The device should not submerge into any liquids and expose it to direct moisture.
There is no gender and age limitation for using the infrared thermometer.
This is not an AP or APG product.
THD2FE Non-contact Forehead Thermometer
Functions
The thermometer has been designed for home use. It’s not meant to replace a visit to the
doctor. Please also remember to compare the measurement result to your regular body
temperature. Please consult with doctor if you have health concerns.
à Please see the “Use of the thermometer”
section to learn how to measure the body
temperature.
The surface mode shows the actual and unadjusted surface temperature which is different from
the body temperature. It can help you monitor if the object temperature is suitable for the baby
or patient, for example the baby’s milk.
à Please see the “Use of the thermometer” section to learn how to measure
the object
temperature.
If the thermometer detects a temperature ≧99.5°F (or 37.5°C) under forehead mode, three
short beep sound will follow one long beep sound to warn the user for the temperature is above
99.5°F (37.5°C).
There are total 25 sets of measurement condition for body temperature.
à When power on, press the “ON/MEM” button to see the temperature records with icon.
In “Power Off” mode, press and hold the “START” button, then press the “ON/MEM” button for
3 seconds, icon “°F” will be switched to icon “°C”. You can also use the same process to
change the LCD display from °C to °F.
NOTE:
Memory clear and Celsius/Fahrenheit switch are together. When you switch Celsius and
Fahrenheit, the Memory will be cleared.
The device setting with buzzer is on, you can set buzzer on/off under Mute mode.
When power on, press and hold the “ON/MEM” button for 3 seconds. The icon
will flash on
the LCD screen and then release the “ON/MEM” button to set MUTE. Thus you will not hear
beep sounds. You can also use the same process to turn off the Mute function.
NOTE: If keep pressing "ON/MEN" button for 2 seconds after
icon flashing, the device will
be power off WITHOUT setting Mute.
Use of the thermometer
Note: If there is any temperature difference between the places where the device is stored and where you are going to measure, subject and the device should
stay in the same room for at least 15 minutes before measurement.
1. Always make sure the probe lens is clean without any damage and the forehead is clean.
Warning: Choking from swallowing small parts and batteries by children or pets is possible, please keep small parts and batteries at places where
children and pets can’t reach.
2. Power on:
Press the “ON/MEM” button (see figure 1).
3. Measuring body temperature on the forehead:
The Non-contact Clinical Thermometer, Model THD2FE is an infrared thermometer intended
for the intermittent measurement of human body temperature in people of all ages.
At least 11 years old (5 years intensive reading experience), no maximum.
þ Temperature measurement range:
Forehead mode: 93.2~108°F (34~42.2°C)
Surface mode: -7.6~176°F (-22~80°C)
þ Operating temperature range: 50~104°F (10~40°C), 15%~85% RH
þ Storage temperature range: It should be stored at room temperature between -4~122°F
(-20~+50°C), RH≦85%
Transportation temperature shall be less than 158°F (70°C), RH≦95%
þ Atmospheric pressure: 800~1013 hPa
þ Comply with ASTM E1965-98, EN ISO 80601-2-56, IEC/EN60601-1-2(EMC),
IEC/EN60601-1(Safety) standards, ISO10993, RoHS.
þ Accuracy:
Forehead mode: ±0.4
o
F (0.2
°C ) within 95~107.6°F (35~42°C),
±0.5
o
F (0.3
°C ) for other range.
Surface mode: ±0.5°F (0.3°C) within 71.6~108°F (22~42.2°C),
others ±4% or ±4°F (2°C) whichever is greater.
þ Temperature indicator, memory and °F / °C switch function
þ Battery: AAA x 2 pcs
þ Battery life: around 3,000 continuous readings.
þ Expected Service Life: 4 years
þ This thermometer converts the forehead temperature to display its “oral equivalent.”
(according to the result of the clinical evaluation to get the offset value)
þ Blue LED Backlight
Blue LED backlight will be automatically turned on after measurement, and automatically
turned off after 2 seconds.
þ Enclosure Rating: IP22
þ Dimensions: 158.0 x 48.0 x 40.2 mm
þ Weight: 100 grams including battery
The device should not submerge into any liquids and expose it to direct moisture.
There is no gender and age limitation for using the infrared thermometer.
This is not an AP or APG product.
˚F / ˚C: Med enheten avslagen, tryck och håll inne ”START”-knappen och tryck sedan på ”ON/MEM”-
knappen i 3 sekunder. ”°F”-symbolen ändras nu till ”°C”-symbolen. Använd samma tillvägagångssätt
för att växla från °C till °F på LCD-skärmen.
OBSERVERA: Rensa minne och växla mellan celsius/fahrenheit är sammankopplade. När du växlar
mellan celsius och fahrenheit så rensas minnet.
THD2FE Non-contact Forehead Thermometer
Functions
The thermometer has been designed for home use. It’s not meant to replace a visit to the
doctor. Please also remember to compare the measurement result to your regular body
temperature. Please consult with doctor if you have health concerns.
à Please see the “Use of the thermometer”
section to learn how to measure the body
temperature.
The surface mode shows the actual and unadjusted surface temperature which is different from
the body temperature. It can help you monitor if the object temperature is suitable for the baby
or patient, for example the baby’s milk.
à Please see the “Use of the thermometer” section to learn how to measure
the object
temperature.
If the thermometer detects a temperature ≧99.5°F (or 37.5°C) under forehead mode, three
short beep sound will follow one long beep sound to warn the user for the temperature is above
99.5°F (37.5°C).
There are total 25 sets of measurement condition for body temperature.
à When power on, press the “ON/MEM” button to see the temperature records with icon.
In “Power Off” mode, press and hold the “START” button, then press the “ON/MEM” button for
3 seconds, icon “°F” will be switched to icon “°C”. You can also use the same process to
change the LCD display from °C to °F.
NOTE:
Memory clear and Celsius/Fahrenheit switch are together. When you switch Celsius and
Fahrenheit, the Memory will be cleared.
The device setting with buzzer is on, you can set buzzer on/off under Mute mode.
When power on, press and hold the “ON/MEM” button for 3 seconds. The icon
will flash on
the LCD screen and then release the “ON/MEM” button to set MUTE. Thus you will not hear
beep sounds. You can also use the same process to turn off the Mute function.
NOTE: If keep pressing "ON/MEN" button for 2 seconds after
icon flashing, the device will
be power off WITHOUT setting Mute.
Use of the thermometer
Note: If there is any temperature difference between the places where the device is stored and where you are going to measure, subject and the device should
stay in the same room for at least 15 minutes before measurement.
1. Always make sure the probe lens is clean without any damage and the forehead is clean.
Warning: Choking from swallowing small parts and batteries by children or pets is possible, please keep small parts and batteries at places where
children and pets can’t reach.
2. Power on:
Press the “ON/MEM” button (see figure 1).
3. Measuring body temperature on the forehead:
The Non-contact Clinical Thermometer, Model THD2FE is an infrared thermometer intended
for the intermittent measurement of human body temperature in people of all ages.
At least 11 years old (5 years intensive reading experience), no maximum.
þ Temperature measurement range:
Forehead mode: 93.2~108°F (34~42.2°C)
Surface mode: -7.6~176°F (-22~80°C)
þ Operating temperature range: 50~104°F (10~40°C), 15%~85% RH
þ Storage temperature range: It should be stored at room temperature between -4~122°F
(-20~+50°C), RH≦85%
Transportation temperature shall be less than 158°F (70°C), RH≦95%
þ Atmospheric pressure: 800~1013 hPa
þ Comply with ASTM E1965-98, EN ISO 80601-2-56, IEC/EN60601-1-2(EMC),
IEC/EN60601-1(Safety) standards, ISO10993, RoHS.
þ Accuracy:
Forehead mode: ±0.4
o
F (0.2
°C ) within 95~107.6°F (35~42°C),
±0.5
o
F (0.3
°C ) for other range.
Surface mode: ±0.5°F (0.3°C) within 71.6~108°F (22~42.2°C),
others ±4% or ±4°F (2°C) whichever is greater.
þ Temperature indicator, memory and °F / °C switch function
þ Battery: AAA x 2 pcs
þ Battery life: around 3,000 continuous readings.
þ Expected Service Life: 4 years
þ This thermometer converts the forehead temperature to display its “oral equivalent.”
(according to the result of the clinical evaluation to get the offset value)
þ Blue LED Backlight
Blue LED backlight will be automatically turned on after measurement, and automatically
turned off after 2 seconds.
þ Enclosure Rating: IP22
þ Dimensions: 158.0 x 48.0 x 40.2 mm
þ Weight: 100 grams including battery
The device should not submerge into any liquids and expose it to direct moisture.
There is no gender and age limitation for using the infrared thermometer.
This is not an AP or APG product.
THD2FE Non-contact Forehead Thermometer
Functions
The thermometer has been designed for home use. It’s not meant to replace a visit to the
doctor. Please also remember to compare the measurement result to your regular body
temperature. Please consult with doctor if you have health concerns.
à Please see the “Use of the thermometer”
section to learn how to measure the body
temperature.
The surface mode shows the actual and unadjusted surface temperature which is different from
the body temperature. It can help you monitor if the object temperature is suitable for the baby
or patient, for example the baby’s milk.
à Please see the “Use of the thermometer” section to learn how to measure
the object
temperature.
If the thermometer detects a temperature ≧99.5°F (or 37.5°C) under forehead mode, three
short beep sound will follow one long beep sound to warn the user for the temperature is above
99.5°F (37.5°C).
There are total 25 sets of measurement condition for body temperature.
à When power on, press the “ON/MEM” button to see the temperature records with icon.
In “Power Off” mode, press and hold the “START” button, then press the “ON/MEM” button for
3 seconds, icon “°F” will be switched to icon “°C”. You can also use the same process to
change the LCD display from °C to °F.
NOTE:
Memory clear and Celsius/Fahrenheit switch are together. When you switch Celsius and
Fahrenheit, the Memory will be cleared.
The device setting with buzzer is on, you can set buzzer on/off under Mute mode.
When power on, press and hold the “ON/MEM” button for 3 seconds. The icon
will flash on
the LCD screen and then release the “ON/MEM” button to set MUTE. Thus you will not hear
beep sounds. You can also use the same process to turn off the Mute function.
NOTE: If keep pressing "ON/MEN" button for 2 seconds after
icon flashing, the device will
be power off WITHOUT setting Mute.
Use of the thermometer
Note: If there is any temperature difference between the places where the device is stored and where you are going to measure, subject and the device should
stay in the same room for at least 15 minutes before measurement.
1. Always make sure the probe lens is clean without any damage and the forehead is clean.
Warning: Choking from swallowing small parts and batteries by children or pets is possible, please keep small parts and batteries at places where
children and pets can’t reach.
2. Power on:
Press the “ON/MEM” button (see figure 1).
3. Measuring body temperature on the forehead:
The Non-contact Clinical Thermometer, Model THD2FE is an infrared thermometer intended
for the intermittent measurement of human body temperature in people of all ages.
At least 11 years old (5 years intensive reading experience), no maximum.
þ Temperature measurement range:
Forehead mode: 93.2~108°F (34~42.2°C)
Surface mode: -7.6~176°F (-22~80°C)
þ Operating temperature range: 50~104°F (10~40°C), 15%~85% RH
þ Storage temperature range: It should be stored at room temperature between -4~122°F
(-20~+50°C), RH≦85%
Transportation temperature shall be less than 158°F (70°C), RH≦95%
þ Atmospheric pressure: 800~1013 hPa
þ Comply with ASTM E1965-98, EN ISO 80601-2-56, IEC/EN60601-1-2(EMC),
IEC/EN60601-1(Safety) standards, ISO10993, RoHS.
þ Accuracy:
Forehead mode: ±0.4
o
F (0.2
°C ) within 95~107.6°F (35~42°C),
±0.5
o
F (0.3
°C ) for other range.
Surface mode: ±0.5°F (0.3°C) within 71.6~108°F (22~42.2°C),
others ±4% or ±4°F (2°C) whichever is greater.
þ Temperature indicator, memory and °F / °C switch function
þ Battery: AAA x 2 pcs
þ Battery life: around 3,000 continuous readings.
þ Expected Service Life: 4 years
þ This thermometer converts the forehead temperature to display its “oral equivalent.”
(according to the result of the clinical evaluation to get the offset value)
þ Blue LED Backlight
Blue LED backlight will be automatically turned on after measurement, and automatically
turned off after 2 seconds.
þ Enclosure Rating: IP22
þ Dimensions: 158.0 x 48.0 x 40.2 mm
þ Weight: 100 grams including battery
The device should not submerge into any liquids and expose it to direct moisture.
There is no gender and age limitation for using the infrared thermometer.
This is not an AP or APG product.
START
START
STAND-BY
(ON-MEM)
LCD
BATTERILUCKA
SENSOR
Swedish
To Next Page
Loading...
