MasterCraft 054-1237-4 User Manual

21
WARNING: When servicing, use only Mastercraft
®
replacement parts. Use of
any other parts may create a safety hazard or cause damage to the tool.
Any attempt to repair or replace electrical parts on this power tool may create a
safety hazard unless repair is performed by a qualified technician.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
155510
Locking button
9
2
240832
Spring
1
3
241592
Spring
1
4
317044
Unit switch
2
5
300100
Enclosure
1
6
312816
Locking button
1
7
215129
Locking pin
2
8
500000
Tapping screw
2
9
242567
Leaf spring of guard
1
10
152516
Adjusting button
1
11
224476
Clamping clamp
1
12
500810
Screw M4x10
2
13
155511
Shaft locking button
2
14
240303
Conical spiral spring
2
15
511004
Closing ring 4
1
16
236038
Bottom worm gear case
1
17
520007
Bearing 606-2RS
1
18
511007
Closing ring 9
1
19
200304
Gear
1
20
214914
Worm
1
21
520007
Bearing 606-2RS
1
22
511006
Closing ring 7
1
23
520013
Bearing 606-2RS
1
24
200901
Worm wheel
1
25
520017
Bearing 608-2RS
1
26
236039
Top worm gear case
1
27
225346
Inner guard
1
28
500816
Screw M4x25
4
29
513002
Woodruff key
1
30
213745
Worm wheel shaft
1
!
PARTS LIST – MODEL 054-1237-4
