CHARGING THE BATTERY
1. Place the charging stand (1) near a
120 V, 60 Hz electrical outlet (Fig. 1).
2. Plug the battery charging stand plug
into a 120 V, 60 Hz wall receptacle.
3. Place the rotary tool (2) into the
charging stand.
NOTES:
a) Make sure the bottom of the rotary tool
(3) is properly resting in the charging stand
behind the retaining web (4). The red
indicator light (5) will turn ON when the
rotary tool is properly placed in the
charger.
b) A new battery or one that is completely
exhausted should be charged for 1½ hours
or until the charger shuts down. The green
indicator light (6) turns ON when the
battery is fully charged. After normal use, a
battery should be fully charged in about 1
hour.
c) If the battery does not charge properly,
or the red indicator light fails to turn ON,
check to make sure the electrical outlet is
“live” and that the temperature range in the
work area is between 0–45° C
(32–113° F).
LED WORKLIGHT
1. To turn the worklight (1) ON, press the
ON/OFF button (2) once (Fig. 2).
2. To turn the worklight OFF, press the
ON/OFF switch a second time.
