24
WARNING: When servicing, use only Mastercraft
®
replacement parts. The use of
any other parts may create a safety hazard or cause damage to the cordless rotary tool.
Any attempt to repair or replace electrical parts on this cordless rotary tool may create a
safety hazard unless repairs are performed by a qualified technician. For more information,
call the Toll-free Helpline, at 1-800-689-9928.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
3120040003
Shaft locking button
1
2
2050080013
Shaft locking spring
1
3
2040160003
Shaft locking pin
1
4
3140110002
Spring clavier
1
5
1130070001
Switch
1
6
3150130015
Cover board of decoration plate
1
7
3110010007
Decoration plate
1
8
3160070001
Energy Indicator cover
1
9
3010180002
Housing
1
10
1180060002
Contact plate
1
11
4030010028
Screw
5
12
1260020001
Battery
1
13
1130030002
Variable speed PCB
1
14
1039010001
Motor
1
15
3190020004
Sponge
1
16
3140060007
Stage positioning ring of power
2
17
4010010013
Bearing 688Z
1
18
2050080014
Snap ring
1
19
2040050052
Shaft
1
20
3150100003
Head nut
1
21
2040280002
Collet
1
22
2040150013
Collet nut
1
!
PARTS LIST
