For best paint removal results, move the gun
slowly and steadily forward at an angle to the
surface to be stripped. This allows you to safely
scrape behind the hot air stream and keeps the
scraper and scraped surface cooler. Holding the
heat gun at an angle also preheats the paint as
you scrape.
The chart below explains the four zones for the
paint removal process (Fig. 6).
Zone Description
1 Warm air preheats the paint
2 Hot air softens the paint
1+2 Heat penetrates complete area
3 Paint can be easily scraped off as soon
as it is softened and the heat gun is
moved forward
4 Stripped surface is allowed to cool
20
WARNING: When servicing,
use only identical replacement parts. Use of any
other part may create a hazard or cause product
damage.
DO NOT abuse power tools. Abusive practices can
damage the tool as well as the workpiece.
WARNING: DO NOT attempt
to modify tools or create accessories. Any such
alteration or modication is misuse and could
result in a hazardous condition leading to possible
serious injury. It will also void the warranty.
Cleaning
Keep air vents clean and unobstructed to allow
maximum airow through the heat gun.
DO NOT use solvents when cleaning plastic
parts. Most plastics are susceptible to damage
from various types of commercial solvents and
may be damaged by their use. Use a clean cloth
dampened with a mild detergent to remove dirt,
dust, oil, grease, etc.
WARNING: Do not at any time
allow brake uids, gasoline, petroleum-based
products, penetrating oils, etc. to come in contact
with plastic parts. They contain chemicals that can
damage, weaken or destroy plastic.
Lubrication
All of the bearings in this heat gun are lubricated
with a sufcient amount of high-grade lubricant
for the life of the unit under normal conditions.
Therefore, no further lubrication is required.
MAINTENANCE
21
OPERATING INSTRUCTIONS
HEAT GUN 054-1252-6
HEAT GUN 054-1252-6
g. 6
