5 U.S. GALLONS (18.9 L) AIR COMPRESSOR 058-9308-0
If any parts are missing or damaged, or if you have any questions, please call 1-800-689-9928.
No. Description Qty No. Description Qty
1 Control panel 1 17 Air tank 1
2 Tank pressure gauge 1 18 Rubber foot 4
3 Bolt, M4 x 10 2 19 Drain valve 2
4 Quick connector 1 20 Hexagon nuts with flange, M6 x 20 4
5 Pressure regulator knob 1 21 Anchor nut 1
6 Outlet pressure gauge 1 22 Check valve 1
7 Tube 1 23 Power cord 1
8 Back shroud 1 24 ON/OFF switch 1
9 Air filter 1 25 Safety relief valve 1
10 Self tapping screw 4 26 Cushion pad 4
11 Pump/motor assembly 1 27 Hexagon nuts with flange 4
12
Hexagon socket cap screws,
M5 x 12
4 28
Cross recessed pan head screws,
M5 x 10
2
13
Hexagon socket cap screws,
M8 x 25
4 29 Flat washer 4
14 Lock washer 2 30 Front shroud 1
15 Grip handle 1 31 Switch retainer
1
16
Pressure transfer tube
1
32 ON/OFF switch assembly
1
