MasterCraft 054-2500-0 User Manual

18
4V LITHIUM-ION COMPACT SCREWDRIVER - 054-2500-0
PARTS LIST
No. Part No. Description No. Part No. Description
01 054250001 Front housing cover 18 054250018 Motor mounting
02 054250002 Shaft 19 054250019 Spring
03 054250003 Washer 20 054250020 Pinion
04 054250004 Ball 21 054250021 Motor
05 054250005 Bushing 22 054250022 F/R button
06 054250006 Gear box housing 23 054250023 Left housing
07 054250007 Cam plate 24 054250024 Battery indication PCB
08 054250008 Screw ST2. 5x8 25 054250025 Control PCB
09 054250009 Screw M3 26 054250026 Charging jack
10 054250010 Outer bracket 27 054250027 Charging LED light
11 054250011 Pin 28 054250028 Li-ion battery
12 054250012 Ring gear 29 054250029 Switch button
13 054250013 Carrier 30 054250030 Working LED button
14 054250014 Planet gear 31 054250031 Right housing
15 054250015 Sun gear 32 054250032 Screw ST2. 5 x 8
16 054250016 Rear washer 33 054250033 Screw ST2. 9 x 12
17 054250017 Screw M2. 5 34 054250034 Adaptor

MasterCraft 054-2500-0 Specifications

General

Brand	MasterCraft
Model	054-2500-0
Category	Power Screwdriver
Language	English
