model no. 054-2516-4 | contact us 1-800-689-9928
10
KEY PARTS DIAGRAM
KEY PARTS DIAGRAM
Not all the accessories illustrated or described are included in standard delivery.
1
2 3
7
4
5
6
No. Description
1 Hex chuck
2 Charging indicator
3 Adjust handle lock switch
4 Forward/reverse rotation switch
No. Description
5 On/off switch
6 Soft handle
7 Sight light
